Masibus LC5296-XP User Manual

Model: LC5296-XP-AT / LC5296-XP/LC5296-XP-I
Doc. Ref. no. :- m61D/om/101
Issue no. 17
User’s Manual Page 7 of 56
2.2 Display & Keys
Model
Display
Specification
LC5296-XP-AT
PV Display
4-Digit, 7-Segment, Red, Character height of
0.56”
SV / Parameter Display
4-Digit, 7-Segment, Green, Character height
of 0.40”
Status Indication
Individual RED Led for Relay, SSR Output,
Manual Status, communication(Rx &Tx)
Status
LC5296-XP
PV Display
4-Digit, 7-Segment, Red, Character height of
0.56”
SV / Parameter Display
4-Digit, 7-Segment, Green, Character height
of 0.40”
Status Indication
Individual RED Led for Relay Status&
communication(Rx &Tx) Status
LC5296-XP-I
PV Display
4-Digit, 7-Segment, Red, Character height of
0.56” or 0.8”
Status Indication
Individual RED Led for Relay Status&
communication(Rx &Tx) Status (Available
based on Ordering Code)
2.3 Output Types
Output types are software selectable from the Key board or Modbus.
Model
Output Type
Description
LC5296-XP-AT
Relay Output
2 Relays
Relay-1
 For PID or ON-OFF Controlling.
 Used as Alarm-1 Output if Output Type is
Linear
Relay-2
 Alarm-2 Output
SSR Output *
Voltage Pulse Output
Available at Terminals of Relay-1
Linear Output
Available at Terminals of Retransmission-1.
Linear Output Type as per selection in
Retransmission-1 Output Type.
LC5296-XP
Relay Output
2 Relays for ON-OFF Controlling
LC5296-XP-I
Relay Output
2 Relays for ON-OFF Controlling (Optional)
 Also, Output Direction [Direct (Cooling) /Reverse (Heating)] is selectable from
software.
 At a time unit can support Relay or SSR Output. (Factory settable)(Specify in
Order Code)
