Masibus LC5296-XP User Manual

Model: LC5296-XP-AT / LC5296-XP/LC5296-XP-I
Doc. Ref. no. :- m61D/om/101
Issue no. 17
User’s Manual Page 51 of 56
41
Cycle time
40041
Int
R + W


42
Output Direction
40042
Int
R + W


43
Manual reset
40043
Int
R + W


44
Sampling rate
40044
Int
R + W


45
Sampling period
40045
Int
R + W


46
%POWER
40046
Int
R + W


47
Auto/Manual
40047
Int
R + W


48
Control low
40048
Int
R + W


49
Control high
40049
Int
R + W


50
Ramp – type
40050
Int
R + W


51
Ramp – rate
40051
Int
R + W


52
Soak - rate
40052
Int
R + W


53
Soak type
40053
Int
R + W


54
offset
40054
Int
R + W


55
Function Key
40055
Int
R + W


56
INLO
40056
Int
R + W


57
INHI
40057
Int
R + W


11.3 Exceptional Response
CODE
MEANING
01
Function code Invalid. It must be 01, 05, 03 or 06.The function code received in
the query is not allowable action for the slave.
02
Illegal address value. The data address received in the query is not an
allowable address for the salve.
03
Illegal data value. A value contained in the query data field is not an allowable
value for the salve.
06
When Master device write some parameters to Slave device, If slave device
busy then it will send 06 code to indicate slave device is busy.
Note:
1. For Model LC5296-XP-AT address 40035 refer to Alarm Set Point-1
For Model LC5296-XP address 40035 refer to Control Set Point-2
2.  : Available for this Model.
 : Not Available for this Model.
3. Any Parameter which is not available for the Model, the value at its
address will be “0”. And it is Not Writable.
4. If Some parameters are blocked in the Menu due to particular
Configuration Settings, value at their respective address will be “0”. And
these are Not Writable.
