Masibus LC5296-XP User Manual

Model: LC5296-XP-AT / LC5296-XP/LC5296-XP-I
Doc. Ref. no. :- m61D/om/101
Issue no. 17
User’s Manual Page 29 of 56
6.5 CALIBRATION MODE
A.CJC
(a.CJC)
Auto Cold
Junction
Compensation
Select Auto Cold Junction Compensation
required or not for TC input Type.
no / yes
0 : NO
1 : YES
YES
Input Type is TC
F.CJC
(F.CJC)
Fix cold junction
Compensation
Set Fix cold junction Compensation
value.
0 to 60.0 °C
0.0
Input Type is TC
& A.CJC is NO
F.KEY
(F.KEY)
Function Key
Select A/M or Soak time
A-M/SOK.T
0 : A-M
1 : SOK.T
SOK.
T
Control output
type is PID
SP.PW
(SP.PW)
SetPointLock
setting
Select No / Yes
NO/YES
0 : NO
1 : YES
NO
VERS
(verS)
Version
Shows the Version of the Current
Firmware
-
PASS
(pass)
Password
Set Device Password
0 to 9999
1
CALIBRATION PARAMETERS
Parameter
(PV display)
Setting Name & Description
Default
Value
Show if Only
Symbol
Name
AMB
(Amb)
Ambient
Ambient Adjustment
-
Input is TC
CALZ
(CALZ)
ZERO
Calibration Zero for PV Input
(SV Display : PV)
-
CALS
(CALS)
SPAN
Calibration Span for PV Input
(SV Display : PV)
-
RTZ1
(rtz1)
Retransmission-1
ZERO
Calibration Zero for
Retransmission Output-1
(SV Display : If voltage: 0.000
If Current: 4.000)
-
Device
Supports
Retransmission
Output
RTS1
(rts1)
Retransmission-1
SPAN
Calibration Span for
Retransmission Output-1
(SV Display : If voltage: 8.000
If Current: 20.00)
-
Device
Supports
Retransmission
Output
RTZ2
(rtZ2)
Retransmission-2
ZERO
Calibration Zero for
Retransmission Output 2
(SV Display : If voltage: 0.000
If Current: 4.000)
-
Device
Supports Dual
Retransmission
Output
