Masibus LC5296-XP User Manual

Model: LC5296-XP-AT/LC5296-XP/LC5296-XP-I
Doc. Ref. no.:- m61D/om/101
Issue no. 17
User’s Manual Page 28 of 56
CO.HI
(Co.Hi)
Control Output
High Limit in %
Control Output High Limit in %.
0.0 to 100.0 %
(It will be always greater then CO.LO)
100
.0
Control output
type is PID
A1TP
(a1tp)
Alarm Type - 1
Refer ALARM Type Table on Page.45
0 to 15
PV.A
L
Output Type is
LIN(Linear)
A2TP
(a2tp)
Alarm Type - 2
Refer ALARM Type Table on Page.45
0 to 15
PV.A
L
A1HY
(a1HY)
Alarm 1
Hysteresis
Set Hysteresis(in °C) for Alarm-1
1 to 100
TC & RTD Input
0.1 to 100.0
RTD.1 Input
1 to 100
Linear Input with DP=0
0.1 to 100.0
Linear Input with DP=1
0.01 to 10.00
Linear Input with DP=2
0.001 to 1.000
Linear Input with DP=3
1
Output Type is
LIN(Linear)
A2HY
(a2Hy)
Alarm 2
Hysteresis
Set Hysteresis(in °C) for Alarm-2
1 to 100
TC & RTD Input
0.1 to 100.0
RTD.1 Input
1 to 100
Linear Input with DP=0
0.1 to 100.0
Linear Input with DP=1
0.01 to 10.00
Linear Input with DP=2
0.001 to 1.000
Linear Input with DP=3
1
A1LC
(a1lC)
Alarm 1 Logic
Set Logic for Alarm-1
norm / flsf
0 : NORM (Normal)
1 : FLSF (Fail-Safe)
Page. 46 shows operation diagram of
different alarm Type for Alarm Logic
NORM (Normal). For Fail-Safe Logic
Alarm will work completely opposite to
Normal behavior. (i.e. for any particular
condition when Relay is ON for Normal
logic, for that condition relay will OFF for
Fail-Safe Logic & vice-versa)
Norm
Output Type is
LIN(Linear)
A2LC
(a2lC)
Alarm 2 Logic
Set Logic for Alarm-2
norm / flsf
0 : NORM (Normal)
1 : FLSF (Fail-Safe)
Norm
A1DY
(a1dy)
Alarm 1 Delay
Alarm Delay is amount of time (in sec),
that Relay-1 will wait before getting ON
after the alarm condition occurs.
1 to 99 sec
1
Output Type is
LIN(Linear)
A2DY
(a2Dy)
Alarm 2 Delay
Alarm Delay is amount of time (in sec),
that Relay-2 will wait before getting ON
after the alarm condition occurs.
1 to 99 sec
1
