Masibus LC5296-XP User Manual

Model: LC5296-XP-AT / LC5296-XP/LC5296-XP-I
Doc. Ref. no. :- m61D/om/101
Issue no. 17
User’s Manual Page 27 of 56
R.D-1
(r.D-1)
Retransmission-1
Direction
Set Direction for the
Retransmission Output-1
rev / dir
0 : REV (REVERSE)
1 : DIR (DIRECT)
EX. If i/p is RTD.1, ZERO=0, SPAN=600,
RTR.1=4-20mA &
RT.D.1=DIR
when PV = 0, RTR o/p = 4mA
PV = 300, RTR o/p = 12mA
PV = 600, RTR o/p = 20mA
RT.D.1=REV
when PV = 0, RTR o/p = 20mA
PV = 300, RTR o/p = 12mA
PV = 600, RTR o/p = 4mA
Refer Retransmission o/p table on Page 54
for more info.
dir
Device Supports
Retransmission
Output& OP.T
(Output Type) is
not LINEAR.
RT-2
(rt-2)
Retransmission 2
Type
Retransmission-2 Output Type
This output is according to PV input.
Zero & Span acts as Min & Max value of
retransmission o/p scale respectively.
0-5v / 1-5v / 0-10v / 4-20 / 0-20
0 : 0-5V
1 : 1-5V
2 : 0-10V
3 : 4-20mA
4 : 0-20mA
Voltage or Current is Jumper Selectable
from the Hardware.
4-20
Device Supports
Dual
Retransmission
Output.
R.D-2
(r.d-2)
Retransmission-2
Direction
Set Direction for the
Retransmission Output-2
rev / dir
0 : REV (REVERSE)
1 : DIR (DIRECT)
DIR
Device Supports
Dual
Retransmission
Output.
OT
(ot)
Output Type
Output Type
rely / ssr/ lin
0 : RELY (Relay)
1 : SSR (Voltage Pulse Output)
2 : LIN (Linear)
Device can support RELAY or SSR
output once at a time. (Factory Settable)
** Device can support Control output type
PID or onoF.(Factory Settable)
Rely
**LIN and SSR
option will not
appear if
COP(Control
Type) is ON-OFF
COP
(Cop)
Control Output
Type
Select Controlling Type for Output
P / Pi / pid
0 : P (Proportional Control)
1 : PI
2 : PID
P
Control output
type is PID
CO.LO
(Co.Lo)
Control Output
Low Limit in %
Control Output Low Limit in %.
0.0 to 100.0 %
(It will be always less then CO.HI)
0.0
Control output
type is PID
