Masibus LC5296-XP User Manual

Model: LC5296-XP-AT/LC5296-XP/LC5296-XP-I
Doc. Ref. no.:- m61D/om/101
Issue no. 17
User’s Manual Page 26 of 56
1 to 99 sec
HY-1
(Hy-1)
Hysteresis – 1
(For Relay-1)
Hysteresis Value (in °C) for Relay-1
during ON-OFF type Control.
1 to 100
TC & RTD Input
0.1 to 100.0
RTD.1 Input
1 to 100
Linear Input with DP=0
0.1 to 100.0
Linear Input with DP=1
0.01 to 10.00
Linear Input with DP=2
0.001 to 1.000
Linear Input with DP=3
1
Control Type is
ON-OFF
DP
(dp)
Decimal Point
Set position of Decimal Point on Display.
0 / 0.0 / 0.00 / 0.000
*0 : 0
*1 : 0.0
2 : 0.00
3 : 0.000
1
Input Type is
Linear,
*if input type is
RTD or TC.
DISP
(disp)
Display Set Point
Set which Set Point to shown in SV
display in RUN mode while device is in
Auto Mode C1.sp / A2.sp / A1.sp
0 : C1.SP (Control Set Point 1)
1 : A2.SP (Alarm Set Point 2)
2 : A1.SP (Alarm Set Point 1)
C1.S
P
Output Type is
Relay or SSR
then A1.SP will
not appear.
BRHT
(brHt)
Brightness
Adjust Brightness of the 7-segment
Display.
10 to 100
100
SRNO
(srno)
Serial No.
Unt ID for Modbus-RS485
Communication
1 to 247
1
Device supports
RS485
Communication.
BAUD
(baud)
Baud Rate
Set Modbus RS485 Communication Baud
Rate
9600 / 19.2k / 38.4k
0 : 9600 (9600 bps)
1 : 19.2K (19200 bps)
2 : 38.4K (38400 bps)
9600
Device supports
RS485
Communication.
RT-1
(rt-1)
Retransmission 1
Type
Retransmission-1 Output Type
This output is according to PV input.
Zero & Span acts as Min & Max value of
retransmission o/p scale respectively.
0-5v / 1-5v / 0-10v / 4-20 / 0-20
0 : 0-5V
1 : 1-5V
2 : 0-10V
3 : 4-20mA
4 : 0-20mA
Voltage or Current is Jumper Selectable
from the Hardware.
4-20
Device Supports
Retransmission
Output.
