Masibus LC5296-XP User Manual

Model: LC5296-XP-AT/LC5296-XP/LC5296-XP-I
Doc. Ref. no.:- m61D/om/101
Issue no. 17
User’s Manual Page 6 of 56
2. SPECIFICATIONS
2.1 Inputs
Analog Input
Input Type
Thermocouple, RTD (Pt100), Current, Voltage
Display Range
Refer Table-2.1
Accuracy
+ (0.25% of FS+ 1 degree) for T/C and RTD input.
+ (0.1% of FS+ 1 count) for Linear input.
ADC Resolution
16 bits
Display Resolution
0.1°C / 1 Count
Sampling Rate
4 Samples/Sec
CJC Error
±3.0 °C Max
Sensor Burnout current
0.25uA
RTD excitation current
0.166mA (Approx)
Allowable wiring resistance for
RTD
Maximum 15 ohms/wire (Conductor
resistance between three wires should be equal)
NMRR
> 40 dB
CMRR
> 120 dB
Temp-co
< 150ppm/°C
Input Impedance
> 1MΩ (Voltage Input)
250Ω (Current Input)
Max Voltage
20VDC
*Use external 250ohms, 0.1% for current Input
Table-2.1 Input Display Range
Input type
Range
PT100 (0.1ºC)
-199.9 to 850.0ºC
PT100 (1ºC)
-200 to850ºC
E
-200 to 1000ºC
J
-200 to1200ºC
K
-200 to1372ºC
T
-200 to400ºC
B
450 to1800ºC
R
0 to1768ºC
S
0 to1768ºC
*4-20mA /1-5VDC,
*0-20mA /0-5VDC
0-10V
-1999 to 9999
(Field Scalable)

Masibus LC5296-XP Specifications

General

Brand	Masibus
Model	LC5296-XP
Category	Controller
Language	English
