Masibus LC5296-XP User Manual

Model: LC5296-XP-AT/LC5296-XP/LC5296-XP-I
Doc. Ref. no.:- m61D/om/101
Issue no. 17
User’s Manual Page 50 of 56
6
SET Type-2
40006
Int
R + W


7
Open Sensor Status
40007
Int
R + W


8
Relay Delay -1
40008
Int
R + W


9
Hysteresis 1
40009
Int
R + W


10
Relay Delay -2
40010
Int
R + W


11
Hysteresis 2
40011
Int
R + W


12
Decimal Point
40012
Int
R + W


13
Display set point
40013
Int
R + W


14
Brightness
40014
Int
R + W


15
Serial Number
40015
Int
R + W


16
Baud Rate
40016
Int
R + W


17
Retransmission o/p
Type -1
40017
Int
R + W


18
Retransmission o/p
direction - 1
40018
Int
R + W


19
Retransmission o/p
Type -2
40019
Int
R + W


20
Retransmission o/p
direction - 2
40020
Int
R + W


21
Control output type
40021
Int
R + W


22
Control type
40022
Int
R + W


23
Alarm-1 Type
40023
Int
R + W


24
Alarm- 2 Type
40024
Int
R + W


25
Alarm-1 hysteresis
40025
Int
R + W


26
Alarm-2 hysteresis
40026
Int
R + W


27
Alarm-1 logic
40027
Int
R + W


28
Alarm-2 logic
40028
Int
R + W


29
Alarm-1 delay
40029
Int
R + W


30
Alarm-2 delay
40030
Int
R + W


31
Auto CJC
40031
Int
R + W


32
Fixed CJC
40032
Int
R + W


33
Version
40033
Int
R


34
Password
40034
Int
R + W


35
Control set point-1
40035
Int
R + W


36
Alarm Set Point-1
Control Set Point-2
(Refer Note-1)
40036
Int
R + W


37
Set Value 2
40037
Int
R + W


38
Proportional band
40038
Int
R + W


39
Integral time
40039
Int
R + W


40
Derivative time
40040
Int
R + W


