Model: LC5296-XP-AT / LC5296-XP/LC5296-XP-I
Doc. Ref. no. :- m61D/om/101
Issue no. 17
User’s Manual Page 3 of 56
7. MENU LAYOUT for LC5296-XP......................................................................... 32
7.1 RUN Time Indication/Function....................................................................... 34
7.2 Set Point Setting ............................................................................................ 34
7.3 CONFIGURATION MODE............................................................................. 34
7.4 CALIBRATION MODE ................................................................................... 38
8. CONTROL FUNCTION ....................................................................................... 40
8.1 ON/OFF Control ............................................................................................. 40
8.2 PID Control .................................................................................................... 41
8.3 Ramp and Soak Function: ............................................................................... 44
9. ALARM OUTPUT ................................................................................................ 45
9.1 ALARM TYPES ............................................................................................. 45
10. CALIBRATION PROCEDURE .......................................................................... 48
10.1 Procedure for CAL-zero and CAL-span ....................................................... 48
10.2 Procedure for RET-zero and RET-span ...................................................... 48
11. COMMUNICATION PROTOCOL–MODBUS RTU ............................................ 49
11.1 INTRODUCTION ......................................................................................... 49
11.2 Modbus Parameter Address ........................................................................ 49
11.3 Exceptional Response .................................................................................. 51
12. Appendix .......................................................................................................... 53
12.1 Troubleshooting ........................................................................................... 53
12.2 ON-OFF LOGIC ........................................................................................... 54
12.3 Retransmission Output Table For OPEN /OVER /UNDER Condition .......... 54
12.4 Control Output Table for OPEN/OVER/ UNDER Condition ......................... 54
12.5 Jumper Settings for Addon Card Selection &RetransmissionOutput Type .. 55
12.6 Load connection ........................................................................................... 56
