SETUP MENU LEVEL 1 (CONTINUED)
LED BRIGHTNESS
The Display screen and all active LED indicators are effected while adjusting this setting.
BUTTONS SETTINGS INSTRUCTIONS
Hold down the
Brightness Button for
5 seconds to access
LED to brightness
options
LED Brightness
Level 3 (default)
Use the Brightness Button to
move between menu options
and the Enter Button to accept
the setting.
Press 2x
LED Brightness
Level 4
Press 3x
LED Brightness
Level 1
Press 4x
LED Brightness
Level 2
SETUP MENU LEVEL 2
Level 2 menu contains parameters and settings that are not changed as frequently as
Level 1. These include alarm volume, alarm silence, alarm delay, clear trend, button
volume, sensitivity, and FastSat parameters. Use the Enter Button to access the menu.
Press the Enter Button again to move to the next menu.
ALARM VOLUME
BUTTONS SETTINGS INSTRUCTIONS
Use the Enter Button
to access the Alarm
Volume menu and to
move between Level
2 menus.
Alarm Volume
Level 3 (default)
Use the Up Button to move
between settings and the
Enter Button to accept the
setting and move to the next
menu screen
OR
let the device time out for 10
seconds to exit without saving
the new setting.
Press Up Once
Alarm Volume
Level 4
Press Up 2x
Alarm Volume
Level 1
Press Up 3x
Alarm Volume
Level 2
operation

Masimo Rad-8 Specifications

General

Display	LED
Pulse Rate Range	25-240 bpm
Pulse Rate Accuracy	±3 bpm
Trend Time	72 hours
SpO2 Range	0-100%
SpO2 Accuracy	± 2 digits (70-100% SpO2)
Power Supply	AC adapter or rechargeable battery
Perfusion Index (PI) Range	0.02% - 20%
PVI Range	0-100
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Relative Humidity	10-95% non-condensing
Altitude	Up to 15, 000 ft (4, 572 m)
