Rad-8 Signal Extraction Pulse Oximeter Operator’s Manual 4-15
4
operation
SETUP MENU LEVEL 3 - (CONTINUED)
RAPID DESAT LIMIT
The Rapid Desat Limit is designed to detect rapid desaturations of 5%, 10%, or 0% below
the low alarm limit and overrides the Alarm Delay feature when activated.
BUTTONS SETTINGS INSTRUCTIONS
Press the Enter Button
again to move to the
next menu.
Rapid Desat
Limit 5%
(default)
Use the Up or Down Button to
move between settings
AND
press the Enter Button to
accept the setting and move to
the next menu.
OR
let the device time out for 10
seconds to exit without saving
the new settings.
Press Up Once
Rapid Desat
Limit 10%
Press Up 2x
Rapid Desat
Limit 0%
ALARM ON/OFF
BUTTONS SETTINGS INSTRUCTIONS
Press the Enter Button
again to move to the
next menu.
Alarm On/Off
(Default ON)
Use the Up or Down Button to
move between settings
AND
press the Enter Button to
accept the setting and move to
the next menu
OR
let the device time out for 10
seconds to exit without saving
the new setting.
Press Up Once
Alarm On/Off*
OFF
Press Up 2x
Alarm Off (rE)**
(Alarm OFF
with reminder)
* Visual alarms are active in this mode.
**When Alarm On/Off is set to "Off rE", the audible alarm "beeps" twice every three minutes to
remind the user that the Rad-8 is currently in alarm status but the audible alarm is muted. Visual
alarms are active in this mode. If an alarm limit is violated, the associated parameter/measurement
label and value flash, the alarm bell flashes red for high priority alarms.

Masimo Rad-8 Specifications

General

Display	LED
Pulse Rate Range	25-240 bpm
Pulse Rate Accuracy	±3 bpm
Trend Time	72 hours
SpO2 Range	0-100%
SpO2 Accuracy	± 2 digits (70-100% SpO2)
Power Supply	AC adapter or rechargeable battery
Perfusion Index (PI) Range	0.02% - 20%
PVI Range	0-100
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Relative Humidity	10-95% non-condensing
Altitude	Up to 15, 000 ft (4, 572 m)
