7-2 Rad-8 Signal Extraction Pulse Oximeter Operator’s Manual
7
specifications
Rad-8 specifications continued
PHYSICAL CHARACTERISTICS
Dimensions:
8.2” x 6.0” x 3.0” (20.8 cm x 15.2cm x 7.6 cm)
Weight: 2.1 lbs. = .908 Kg. = 32 oz
Trending
72 hours of trending at 2 second resolution
Mode
Averaging mode: 2, 4, 8,10, 12, 14 or 16 seconds
9
Sensitivity: Normal, Maximum, and APOD
Alarms
Audible and visual alarms for high and low saturation and pulse rate (SpO
2
range 1-99%, pulse rate
range 30-235 bpm)
Sensor condition, system failure and low battery alarms
High Priority Audible Alarm
800 Hz tone, 5 pulse burst, pulse spacing: 0.250s,
0.250s, 0.500s, 0.250s, repeat time:10s
Low Priority Audible Alarm
500 Hz tone, 3 pulse, repeat time: 5s
High Priority Visual Alarm Red flashing 2 seconds (0-5 Hz)
Alarm Volume:
High: 85 dB (min)
Low: 45 dB (min)
Display/Indicators
Data display: %SpO
2
, pulse rate, alarm status, alarm silenced status, AC power, Signal IQ/pleth bar,
perfusion index bar, battery status
Type:
LED
Display update rate 1 second
Output Interface
Serial RS-232, Philips VueLink, Nurse Call
Compliance
Safety Standard for Medical Equipment IEC 60601-1 2
nd
Edition
UL 60601-1
CAN/CSA C22.2 No. 601-1
JIS 0601-1
Type of Protection Class 1 (AC power), Internally powered (battery power)
Degree of Protection-Patient Cable: Type BF, Defib Proof -Applied Part
Rad-8 Mode of Operation: Continuous
EMC Standard EN60601-1-2, Class B
1 SpO
2
was determined by testing on healthy adult volunteers in the range 60%-100% SpO
2
against a laboratory
CO-Oximeter. SpO
2
accuracy was determined on 16 neonatal NICU patients ranging in age from 7 to 135 days old
and weighting between 0.5 and 4.25 kgs. Seventy-nine (79) data samples were collected over a range of 70 - 100%
SaO2 with a resultant accuracy of 2.9% SpO
2.
. Contact Masimo for testing specifications.
2. The arterial oxygen saturation accuracy during no motion
only applies to LNOP
®
Blue SpO
2
adhesive sensors.
To Next Page
