4-18 Rad-8 Signal Extraction Pulse Oximeter Operator’s Manual
4
SETUP MENU LEVEL 3 (CONTINUED)
DAY
BUTTONS SETTINGS INSTRUCTIONS
Press the Enter Button
again to move to the
next menu.
Day (current day)
(default is set to
internal clock)
Confirm setting and press
Enter.
NOTE: Pressing Enter while
on Yes will clear trend.
Use the Up or Down Button
to move between settings
AND
press the Enter Button to
accept the setting and move
to the next menu
OR
let the device time out for
10 seconds to exit without
saving the new setting.
Press Up Once
and press Enter
Day
Sets Day (0-31)
Press Up Once
and press Enter
Day
(defaults to Yes)
HOUR
BUTTONS SETTINGS INSTRUCTIONS
Press the Enter Button
again to move to the
next menu.
Hour
(defaults is set
to internal clock)
Confirm setting and press
Enter.
NOTE: Pressing Enter while on
Yes will clear trend.
Use the Up or Down Button
to move between settings
AND
press the Enter Button to
accept the setting and move
to the next menu
OR
let the device time out for 10
seconds to exit without saving
the new setting.
Press Up Once
and press Enter
Hour
Sets Hour (0-23)
Press Up Once
and press Enter
Hour
(defaults to Yes)
operation

Masimo Rad-8 Specifications

General

Display	LED
Pulse Rate Range	25-240 bpm
Pulse Rate Accuracy	±3 bpm
Trend Time	72 hours
SpO2 Range	0-100%
SpO2 Accuracy	± 2 digits (70-100% SpO2)
Power Supply	AC adapter or rechargeable battery
Perfusion Index (PI) Range	0.02% - 20%
PVI Range	0-100
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Relative Humidity	10-95% non-condensing
Altitude	Up to 15, 000 ft (4, 572 m)
