Stork Vitals+ Basic Setup and Use of Stork
Masimo Corporation 28 www.masimo.com
Boot Size Selection
When sizing, your baby's heel should be all the way back against
the boot. It is acceptable if the baby's toes overhang a little, as
shown.
If the toes hang over farther than the picture, or the sensor does
not fit within the desired zone (A), use a larger boot.
Strap Sizes
Straps come in 4 sizes. The small and medium boots come attached with
strap sizes 3 and 4. Size 1 and 2 come in separate packaging.
Attaching the Stork Sensor to the Boot
1. Slide the longer strap on to the top of the boot (will be near
baby’s ankle) and slide the shorter strap onto the sensor.
To remove the strap, simply slide back off.
2.
Insert the sensor into the boot at an angle, toe end first, with the
Masimo logo facing down.
3.
Press down to secure the sensor. The sensor should sit flush in the
boot.
