Electromagnetic Immunity
Voltage
Interruptions on
power supply
input lines
IEC 61000-4-11
0% UT,
250/300 cycle
0% UT, 250/300
cycle
Radiated RF
IEC 61000-4-3
10 V/m 10 V/m Performed over 80 MHz to 2.7 GHz
Note 1: At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reflection from structures, objects and people.
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land
mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically
with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic
site survey should be considered. If the measured field strength in the location in which the ME Equipment is
used exceeds the applicable RF compliance level above, the ME Equipment should be observed to verify normal
operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting or
relocating the ME Equipment.
1
U
T
: Rated voltage for the equipment.
Test Specifications for ENCLOSURE PORT IMMUNITY to RF
Wireless Communication Equipment
Test
Frequency
(MHz)
Band
(a)
(MHz)
Service (a) Modulation (b) Maximum
Power
(W)
Distance
(m)
Immunity
Test Level
(V/m)
385 380-395 TETRA 400
Pulse
modulation (b)
18 Hz
1.8 0.3 27
450 430-470 GMRS 460, FRS 460
FM (c)
+/- 5 kHz
deviation
1 kHz sine
2 0.3 28
710
745
780
704-787 LTE Band 13, 17
Pulse
modulation (b)
217 Hz
0.2 0.3 9
810
870
930
800-960
GSM 800/900, TETRA 800, iDEN
820, CDMA 850, LTE Band 5
Pulse
modulation (b)
18 Hz
2 0.3 28
1720
1845
1970
1700-
1990
GSM 1800; CDMA 1900; GSM
1900; DECT; LTE Band 1, 3. 4.
35: UMTS
Pulse
modulation (b)
217 Hz
2 0.3 28
2450
2400-
2570
Bluetooth, WLAN, 802.11
b/g/n, RFID 2450, LTE Band 7
Pulse
modulation (b)
217 Hz
2 0.3 28
5240
5500
5785
5100-
5800
WLAN 802.11 a/n
Pulse
modulation (b)
217 Hz
0.2 0.3 9
