Stork Vitals+ Appendix
Masimo Corporation 51 www.masimo.com
Test
Frequency
(MHz)
Band
(a)
(MHz)
Service (a) Modulation (b) Maximum
Power
(W)
Distance
(m)
Immunity
Test Level
(V/m)
Note: If necessary to achieve the IMMUNITY TEST LEVEL, the distance between the transmitting antenna and
the ME EQUIPMENT or ME SYSTEM may be reduced to 1 m. The 1 m test distance is permitted by IEC 61000-4-3.
(a) For some services, only the uplink frequencies are included.
(b) The carrier shall be modulated use a 50% duty cycle square wave signal.
(c) As an alternative to FM modulation, 50% pulse modulation at 18 Hz may be used because while it does not
represent actual modulation, it would be worst case.
Recommended Separation Distances
Recommended Separation Distance Between Portable and Mobile RF Communication Equipment and the ME
Equipment
The ME Equipment is intended for use in an electromagnetic environment in which radiated RF disturbances are
controlled. The customer or the user of the ME Equipment can help prevent electromagnetic interference by
maintaining a minimum distance between portable and mobile RF communications equipment (transmitters)
and the ME Equipment as recommended below, according to the maximum output power of the communication
equipment.
Rated maximum output power of transmitter (W) Separation Distance According to Frequency of Transmitter
(m)
d = 0.6*Sqrt (P)
0.01 0.06
0.1 0.19
1 0.6
10 1.9
100 6
For transmitters rated at a maximum output power not listed above, the recommended separation distance d
in meters (m) can be estimated using the equation applicable to the frequency of the transmitter, where P is
the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer.
Note 1: At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reflection from structures, objects and people.
Stork Camera
Camera Status Light
The indicator on the Stork Camera shows the connection and operational status.
Color/Behavior What does it mean?
Slowly Blinking White The sensor is not actively monitoring.
Solid White The sensor is actively monitoring with a successful connection to the
Masimo Cloud.
Blinking Green The camera is ready for pairing to the smart phone/Stork app or to be
connected to the wireless network.
