11.1 wxPropView 111
Mode Description
Continuous Free running, no external trigger signal needed.
OnDemand Image acquisition triggered by command (software trigger).
OnLowLevel As long as trigger signal is Low camera acquires images with own timing.
OnHighLevel As long as trigger signal is High camera acquires images with own timing.
OnFallingEdge Each falling edge of trigger signal acquires one image.
OnRisingEdge Each rising edge of trigger signal acquires one image.
OnHighExpose Each rising edge of trigger signal acquires one image, exposure time corresponds to pulse
width.
OnLowExpose Each falling edge of trigger signal acquires one image, exposure time corresponds to pulse
width.
OnAnyEdge Start the exposure of a frame when the trigger input level changes from high to low or from
low to high.
Now, define on which pin the trigger signal is connected to.
Figure 40: TriggerSource
