124 Appendix B: Technical information
Matrox Solios GigE (starting from version 100)
Operating voltage and
current
Typical: 3.3 V, 2.2 A = 7.26 W
Typical 12.0 V, 0.79 A = 9.48 W
Total (typical): 16.74 W.
I/O Specifications
Input signals in
LVDS for mat
111 Ohm differential termination (typical).
Input current: -150 μA (min) to +80 μA (max).
Input voltage:
• common-mode: -4 V (min) to 5 V (max).
• differential threshold: low of -50 mV (min); high of 50 mV (max).
I/O signals in TTL
format
49.9 Ohms series terminations with 1 nF capacitor to ground.
Input current: -1 μA (min) to +1 μA (max).
Input voltage threshold: low of 0.8 V (max); high of 2.0 V (min).
High-level output current: -32 mA (max).
Low-level output current: +64 mA (max).
Output voltage: low of 0.55 V (max); high of 2.0 V (min).
Output signals in
TTL format
49.9 Ohms series terminations with 1 nF capacitor to ground.
High-level output current: -32 mA (max).
Low-level output current: +64 mA (max).
Output voltage: low of 0.55 V (max); high of 2.0 V (min).
Opto-coupled input
signals
511 Ohm series termination.
Input current:
• low: 250 μA (max).
• high: 5 mA (min) (6.3 mA recommended) to 15 mA (max) (10 mA recommended).
Input voltage (with 511 Ohm series resistor only): low of 0.8 V (max); high of 4.06 V (min) (4.72 V recommended).
