Processing FPGA 97
Processing FPGA
Depending on your application requirements, you can purchase the board with a
Processing FPGA implemented using one of the following two supported FPGA
chips.
High-speed serial interface
The Processing FPGA includes a 32-channel (16 channels per direction),
high-speed serial interface to communicate with the acquisition section of the
Matrox Solios boards. Each channel has a data rate of 462 Mbits/sec, for a total
of 924 Mbytes/sec per direction.
PCI-X interface
The 64-bit PCI-X interface allows the Processing FPGA to communicate with the
Host. It is 64-bits wide and runs at 100 MHz, providing a throughput of up to
800 Mbytes/sec. The implementation of the PCI-X interface will vary depending
on the requirements of the application.
Altera Stratix I package
C5 speed grade
780 pin count
EP1S30 EP1S40
LEs 32,470 41,250
DSP blocks 12 14
DSP block 9-bit elements 96 112
PLLS 10 12
M512 RAM blocks 295 384
M4K RAM blocks 171 183
MRAM blocks 4 4
Total RAM bits 3,317,184 3,423,744
