Matrox Solios Series - Performance; Supported Video Sources

Matrox Solios GigE acquisition section 87
Performance
The video timing parameters supported by the board are as follows:
Note that the length and quality of your cables can influence the reliability of
image acquisition. Longer or poor quality cables can increase the probability of
dropping packets. You can miss frames if packets are dropped. The MIL driver
for Matrox Solios GigE only implements a dropped-packet detection mechanism;
it does not have a recovery mechanism. If packets are dropped, you can either
receive an error (default) or the corrupted frame.
Supported video sources
Matrox Solios GigE supports simultaneous acquisition from up to four
independent frame, field, and line-scan video sources that transfer images in GigE
Vision format with the following pixel types. Matrox Solios GigE can convert
incoming images to the following formats.
Maximum
Number of bytes / line (including sync and blanking) 64 K
Number of lines / frame (including sync and blanking) 64 K
Pixel clock 10/100/1000 Mbps
Bandwidth (theoretical)
4 Gbits/sec
1
1. The bandwidth numbers assume the raw transfer of data from the video source to the Host. If a conversion is performed, the
total available bandwidth might be reduced (since the theoretical maximum bandwidth of the Host interface is limited to
800 Mbytes/sec.).
Bandwidth per port (theoretical) 1 Gbit/sec
Supported pixel
types
Possible conversion formats
1
Mono-8 Mono-16 BGR-24/
RGB-24
BGR-32/
RGB-32
BGR-48 YUV-16 YCbCr-16 YUV-20
(4:2:2)
YCbCr-20
(4:2:2)
Mono-8 - O X X O X X O O
Mono-16 X - X X X X X 0 0
BGR-24/RGB-24 X O - X O X X 0 O
BGR-30 X X X X X X X O O
BGR-32/RGB-32 O O O - O O O O O
BGR-48 X X X X - X X O O
MonoPacked-10 X X O O O O O O O
MonoPacked-12 X X O O O O O O O
YUV-16 X O X X O - X O O
1. X: Conversion available -:Raw Transfer, no conversion required O: Conversion NOT available
