Inspecting the Matrox Solios package 25
Available separately
You might have also ordered one or more of the following:
• MIL, which includes ActiveMIL and Matrox Inspector
1
; MIL-Lite, which
includes ActiveMIL-Lite. Matrox Intellicam is included with each of the
aforementioned software packages.
• DVI-TO-8BNC/O, an 8-foot (2.4 m) input cable with a DVI connector on one
end and both 8 BNCs and open-ended wires on the other end. This cable is meant
to connect to Matrox Solios eA/XA. The open-ended wires allow you to connect
to the synchronization and control signals of the module.
Important To connect the output of a display board (with a DVI output connector) to the
analog video input connectors, you can use a standard cable (DVI-I to DVI-I or
DVI-A to DVI-A cable) if the display board encodes the synchronization signals
on the video data (sync on green). Otherwise, you must use the Matrox
DVI-TO-8BNC/O cable or a custom cable that re-routes the synchronization
signals to the appropriate pins.
❖ If needed, you can purchase a Camera Link or PoCL Camera Link cable from the
video source manufacturer, 3M Interconnect Solutions for Factory Automation,
Intercon 1, or other third parties.
• SOLCLBACCxxPAK accessory kit, which allows you to replace the DB-15
auxiliary I/O connector on Matrox Solios eCL/XCL-B with a DB-9 connector.
In this case, the DB-9 connector has the same pinout as auxiliary I/O connector 1
(DB-9) on the adapter board of other Matrox Solios eCL/XCL boards. Note
however, when using the optional DB-9 connector, some DB-15 signals are not
available.
1. As of MIL 9.0.
