Matrox Solios eCL/XCL acquisition section 59
write to four. This means that using Matrox Solios eCL/XCL-F, for example, you
could only grab from an 8-tap x 8-bit video source if four of the taps carry pixels
that are sequential to the other four taps. To establish the number of
non-sequential memory regions to which your video source must write, refer to
the documentation accompanying your video source.
Matrox Solios eCL/XCL-B also supports power-over Camera Link (PoCL) video
sources. The PoCL protection on-board fuse can sustain a current of 0.4 A at up
to 45°C.
ChannelLink receivers
Matrox Solios eCL/XCL-B uses one ChannelLink receiver for video input(s).
Matrox Solios eCL/XCL dual-Base/single-Medium uses two ChannelLink
receivers that can be used synchronously (single-Medium mode) or
asynchronously (dual-Base mode). Finally, Matrox eCL/XCL-F uses three
ChannelLink receivers synchronously.
Each ChannelLink receiver on Matrox Solios eCL/XCL can receive up to 24 bits
of video data and 4 bits of synchronization and field data from the video source,
as serialized data over four LVDS pairs. A clock is received from the video source
over a fifth LVDS pair.
Tn: tap n, where n indicates the tap.
T1 T1
T2 T2
T5 T5
T6 T6
T7 T7
T8 T8
T3 T3
T4 T4
Supported tap configuration
T1
T2
T1
T2
T5
T6
T5
T6
T7
T8
T7
T8
T3
T4
T3
T4
Tap configuration not supported
