Connectors on Matrox Solios GigE 159
Internal auxiliary I/O connector
The internal auxiliary I/O connector is a 30-pin low-profile IDC connector. It is
used to transmit timing and synchronization signals, and transmit/receive
auxiliary signals. The connector is located on the top edge of the board, making
the signals accessible from inside the computer enclosure.
The pinout for this connector is as follows. Refer to the description of the external
auxiliary I/O connectors to establish if an auxiliary signal is specific to an
independent acquisition path and the type of signals that can be routed onto it.
Pin Signal Description Pin Signal Description
1 AUX(TRIG)_OPTO_IN0+ Opto-isolated auxiliary 0 (input) for
an unspecified acq. path (positive).
2 AUX(TRIG)_OPTO_IN0- Opto-isolated auxiliary 0 (input) for
an unspecified acq. path (negative).
3 AUX(TRIG)_OPTO_IN1+ Opto-isolated auxiliary 1 (input) for
an unspecified acq. path (positive).
4 AUX(TRIG)_OPTO_IN1- Opto-isolated auxiliary 1 (input) for
an unspecified acq. path (negative).
5 AUX(TRIG)_OPTO_IN2+ Opto-isolated auxiliary 2 (input) for
an unspecified acq. path (positive).
6 AUX(TRIG)_OPTO_IN2- Opto-isolated auxiliary 2 (input) for
an unspecified acq. path (negative).
7 AUX(TRIG)_OPTO_IN3+ Opto-isolated auxiliary 3 (input) for
an unspecified acq. path (positive).
8 AUX(TRIG)_OPTO_IN3- Opto-isolated auxiliary 3 (input) for
an unspecified acq. path (negative).
9 GND Ground. 10 GND Ground.
11 AUX(TRIG)_TTL_IO_6 TTL auxiliary 6 (input/output) for
an unspecified acq. path.
12 AUX(TRIG)_TTL_IO_7 TTL auxiliary 7 (input/output) for an
unspecified acq. path.
13 AUX(TRIG)_TTL_OUT10 TTL output auxiliary 10 (output) for
an unspecified acq. path 0.
14 AUX(TRIG)_TTL_OUT11 TTL auxiliary 11(output) for an
unspecified acq. path.
15 AUX(TRIG)_TTL_OUT14 TTL output auxiliary 14 (output) for
an unspecified acq. path.
16 AUX(TRIG)_TTL_OUT15 TTL auxiliary 15 (output) for an
unspecified acq. path.
17 GND Ground. 18 GND Ground.
19 AUX(TRIG)_TTL_IO_8 TTL auxiliary 8 (input/output) for
an unspecified acq. path.
20 AUX(TRIG)_TTL_IO_9 TTL auxiliary 9 (input/output) for an
unspecified acq. path.
21 AUX(EXP)_TTL_OUT12 TTL auxiliary 12 (output) for an
unspecified acq. path.
22 AUX(EXP)_TTL_OUT13 TTL auxiliary 13 (output) for an
unspecified acq. path.
23 AUX(EXP)_TTL_OUT16 TTL auxiliary 16 (output) for an
unspecified acq. path.
24 AUX(EXP)_TTL_OUT17 TTL auxiliary 17 (output) for an
unspecified acq. path.
25 GND Ground. 26 GND Ground.
27 AUX(TRIG)_LVDS_IN4+ LVDS auxiliary 4 (input) for an
unspecified acq. path (positive).
28 AUX(TRIG)_LVDS_IN5+ LVDS auxiliary 5 (input) for an
unspecified acq. path (positive).
29 AUX(TRIG)_LVDS_IN4- LVDS auxiliary 4 (input) for an
unspecified acq. path (negative).
30 AUX(TRIG)_LVDS_IN5- LVDS auxiliary 5 (input) for an
unspecified acq. path (negative).
