158 Appendix B: Technical information
24 AUX(EXP)_TTL_OUT13 TTL auxiliary 13 (output) for an unspecified acq. path.
Supported signals: exposure outputs 0-7, user-defined 13 (output).
25 GND Ground.
26 GND Ground.
27 NC Not connected.
28 NC Not connected.
29 NC Not connected.
30 NC Not connected.
31 AUX(TRIG)_OPTO_IN1+ Opto-isolated auxiliary 1 (input) for an unspecified acq. path (positive).
Supported signals: timer-trigger input 1, timer-clock input 1, user-defined 1 (input).
32 AUX(TRIG)_OPTO_IN2- Opto-isolated auxiliary 2 (input) for an unspecified acq. path (negative).
See pin 17 for more information.
33 GND Ground.
34 GND Ground.
35 AUX(EXP)_TTL_OUT10 TTL auxiliary 10 (output) for an unspecified acq. path.
Supported signals: exposure output 0-7, user-defined 10 (output).
36 AUX(EXP)_TTL_OUT15 TTL auxiliary 15 (output) for an unspecified acq. path.
Supported signals: exposure output 0-7, user-defined 15 (output).
37 GND Ground.
38 AUX(TRIG)_TTL_IO_9 TTL auxiliary 9 (input/output) for an unspecified acq. path.
Suported signals: exposure output 0-7, timer-trigger input 9, timer-clock input 9,
user-defined 9 (input/output).
39 AUX(EXP)_TTL_OUT16 TTL auxiliary 16 (output) for an unspecified acq. path.
Supported signals: exposure output 0-7, user-defined 16 (output).
40 GND Ground.
41 AUX(TRIG)_LVDS_IN4+ LVDS auxiliary 4 (input) for an unspecified acq. path (positive).
Supported signals: timer-trigger input 4, timer-clock input 4, user-defined 4 (input).
42 NC Not connected.
43 NC Not connected.
44 NC Not connected.
Pin Signal Description
