Connectors on Matrox Solios eCL/XCL dual-Base/single-Medium and eCL/XCL-F boards 137
To build your own cable, you can purchase the following parts:
These parts can be purchased from third parties such as Digi-Key Corporation
(www.digikey.com).
Pin Signal Description
1 P0_TTL_AUX_IO_0 TTL auxiliary input/output 0 for acq. path 0.
Supported signals: exposure output 2, trigger input 0, user-defined input/output 2, field input.
2 P0_OPTO_AUX_IN0- Opto-isolated auxiliary input 0 for acq. path 0 (negative).
See pin 7 for more information.
3 P0_LVDS_AUX_IN0- LVDS auxiliary input 0 for acq. path 0 (negative).
See pin 8 for more information.
4 P0_OPTO_AUX_IN1+ Opto-isolated auxiliary input 1 for acq. path 0 (positive).
Supported signals: trigger input 1, user-defined input 1.
5 P0_OPTO_AUX_IN1- Opto-isolated auxiliary input 1 for acq. path 0 (negative).
See pin 4 for more information.
6GND Ground.
7 P0_OPTO_AUX_IN0+ Opto-isolated auxiliary input 0 for acq. path 0 (positive).
Supported signals: trigger input 0, user-defined input 0, field input.
8 P0_LVDS_AUX_IN0+ LVDS auxiliary input 0 for acq. path 0 (positive).
Supported signals: trigger input 0, user-defined input 5, field input, or quadrature input bit 0.
9 NC Not connected.
Manufacturer: NorComp, Inc.
Connector: 172-E09-102-031
Backshell: 970-009-010-011
