• Auxiliary, multi-purpose signals, which can be configured as user-defined signals,
or to some other functionality depending on the auxiliary signal (for example, as
trigger input, field polarity input, timer-clock input, or exposure output signals).
The number of signals each board supports is given in the table below.
• Matrox Solios eA/XA also has a bi-color LED per timing and control section to
monitor PLL operation and sychronization signal input. Matrox Solios
eA/XA Quad has a total of four LEDs, Matrox Solios eA/XA Dual has two LEDs,
while Matrox Solios eA/XA Single has one LED.
• All Matrox Solios eCL/XCL boards
1
support an integrated quadrature decoder.
Board Auxiliary signals available
Matrox Solios eCL/XCL-B
8
1
1. This is the number of auxiliary signals available when using the DB-15 auxiliary I/O connector; if replaced with the optional
DB-9 connector from the SOLCLBACCxxPAK accessory kit, less auxiliary signals are available (see the pinout of the auxiliary
I/O connector in Appendix B: Technical information).
Matrox Solios eCL/XCL dual-Base 18
Matrox Solios eCL/XCL single-Medium + eCL/XCL-F 14
Matrox Solios eA/XA Single 13
Matrox Solios eA/XA Dual 18
Matrox Solios eA/XA Quad 28
Matrox Solios GigE 18
1. For the standard Camera Link speed Matrox Solios XCL dual-Base/single-Medium
boards (66 MHz), starting from version 100.
