Mounting on the wall. This TV is designed to be 4.
wall-mounted with a standard 200 mm x 100 mm
mounting kit designed for flat-panel TVs (sold
separately). Mount this unit according to the
instructions included in the mounting kit.
Remove the base stand before mounting the unit
on the wall.
Installing / Removing the Base Stand
The LCD Display is very fragile, and must be protected at all times when removing the base stand. Be sure that no hard or
sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. DO NOT exert pressure
on the front of the unit at any time because the screen could crack.
Disconnect all cables connected to the unit.1.
Lay the unit down on a flat surface with the back side 2.
facing up. Please make sure to place a soft cushioned
material (such as a pillow or thick piece of foam)
beneath the screen.
To remove the base stand, untighten all screws in an 3.
anti-clockwise directions.
To install the base stand, tighten all screws in a 5.
clockwise direction.
200 mm
100 mm
Four mounting holes
(size M5 screw)
