LED Indicators 1 - 7
Quick Start Guide
1
LED Indicators
The LED indicators on the computer display helpful information about the current status of the computer.
*Note: The powered USB 2.0 port (see Figure 1 - 6 on page 1 - 12) may be toggled on /off by means of the Fn + Power
Button key combination. When the powered USB port is on it will supply power when the system is off but still powered
by the AC/DC adapter plugged into a working outlet, or powered by the battery with a capacity level above 20% (this may
not work with certain devices - see page 8 - 11).
Icon Color Description Icon Color Description
Orange DC Power is Plugged In Blue Power Button
Blinking Orange
The Powered USB Port is
On*
Green The Computer is On Green Hard Disk Activity
Blinking Green
The Computer is in Sleep
Mode
Green
The (optional) Wireless LAN
Module is Powered On
Orange The Battery is Charging Orange
The (optional) Bluetooth
Module is Powered On
Green The Battery is Fully Charged
Table 1 - 1 - LED Indicators
Blinking Orange
The Battery has Reached
Critically Low Power Status
