Section 6: Keypad Operation
6.1 Partition Keypads
A partition keypad is a keypad that can access one partition. You
can assign a keypad to a partition when you enroll it (see
4.1
”Enrolling Keypads and Modules’), or in the Partition Assign-
ment section (see below).
The partition keypad will primarily control the partition to which
it is assigned. However, a user will also be able to control other
partitions from the partition keypad, if that user’s access code
allows it.
When a user enters their code to disarm the partition at a partition
keypad, the partition to which the keypad is assigned will disarm.
The user will then have the option to enter their code again to dis
-
arm the other partitions enabled for their code.
Partition Assignment
To change the partition assignment of a keypad:
1. Enter reference number [0012XX00], where XX = the key-
pad number.
2. Enter the number of the partition you want the keypad
assigned to: (01) - (08), or (00) for Global assignment.
Partition Toggle Options
Partition keypads can be programmed to operate according to the
following options. To program these toggle options, enter refer
-
ence number [0100XX01] where XX = partition number. Press [?]
to toggle each option ON or OFF. The programming will affect all
keypads assigned to the selected partition.
• Display Clock - If enabled, the partition keypad(s) will dis-
play the time and date when not in use (default=Yes).
• Display Clock While Stay Armed - If enabled, the partition
keypad(s) will display the time and date when stay armed.
• Disp Exit Time - If enabled, the partition keypad(s) will dis-
play the exit delay time during the exit delay (default=Yes).
• System Alarms - If enabled, the partition keypad(s) will dis-
play ’Partition X in Alarm’ and will beep (five seconds on;
five seconds off) when any other partition is in alarm. This
notification will end when the alarm is cleared or when any
key is pressed on the partition keypad (default=No).
• System Status - If enabled, the partition keypad(s) will dis-
play the status (Ready, Not ready, Armed, alarm memory!,
Force armed) of all active partitions on the system. If dis-
abled, the partition keypads will not display partition status.
This option overrides the clock display option (default=No).
The operation and functionality of the Fire, Auxiliary and Panic
keys are also programmable for partition keypads. For more infor
-
mation regarding the FAP keys, see 6.6 ”Fire, Auxiliary and Panic
Keys’.
6.2 Global Keypads
Unlike a partition keypad, a global keypad is not assigned to a sin-
gle partition. Rather, a global keypad can be used to access all par-
titions on the system. You can assign a keypad to be global when
you enroll it (see
4.1 ”Enrolling Keypads and Modules’), or in the
Partition Assignment section (ref # [0015XX00]).
Global keypads should be placed in common or global areas of
the premises, such as points of entry/exit or reception areas, where
the ability to arm and disarm more than one partition at a time is
required.
When a user enters their code to disarm a partition at a global key-
pad, the system will ask the user to select which partitions they
wish to disarm. The system will only allow the user to disarm the
partitions for which their access code is enabled.
Global Keypad Options
Global keypads can be programmed to operate according to the
following options. To program these toggle options, enter refer
-
ence number [000200]. Press [?] to toggle each option ON or OFF.
The programming will affect all global keypads.
• Global Clock: If enabled, the time and date will be displayed
on global keypads when they are not in use (default=Yes).
• Global Trouble: If enabled, when a trouble condition is pres-
ent on the system, the trouble menu can be viewed from
global keypads. If disabled, global keypads will not list trou
-
ble conditions (default=Yes).
• Global Alarms: If enabled, the global keypads will sound the
buzzer and display the message ’[Partition label] In Alarm’
when any partition is in alarm. The keypad buzzer will be
silenced and the message will be cleared when the alarm has
been restored or any key is pressed on the keypad. If disabled,
global keypads will not indicate alarms (default=No).
• Globl Sys Stat: If enabled, global keypads will display the
status (
Ready, Not ready, Armed, alarm memory!, Force
armed) of all partitions on the system. If disabled, global key
-
pads will not display partition status. This option overrides
the clock display option (default=No).
• Global Entry: If enabled, global keypads will sound an entry
delay for all partitions. If disabled, the entry delay will only
be annunciated if all partitions are armed (default=No).
The operation and functionality of the Fire, Auxiliary and Panic
keys are also programmable for global keypads. For more infor
-
mation regarding the FAP keys, see 6.6 ”Fire, Auxiliary and Panic
Keys’.
6.3 Keypad Toggle Options
Entry / Exit Delay Tones
Ref #: [0012XX01], where XX = keypad number
You can turn off the entry and/or exit delay warning tones for each
keypad enrolled on the system. The entry/exit delay tones are on
by default.
Function Key Options
Ref #: [0012XX01], where XX = LCD45X1 keypad number
On each keypad, you can program each function key so that users
will need to enter an access code before the panel performs the
function. To do this, turn on the ’Funct. X Code’ toggle option for
that key. The default setting is OFF for each key.
NOTE: Some function key types will require an access code entry
regardless of the programming in this section. See section
6.11
”Function Key Programming’ for more information.
