Appendix C: Zone Reporting Codes
For notes on Contact ID and SIA reporting codes, see Appendix A.
Zone Definition Contact ID Auto Rep Codes* SIA Auto Rep Codes* *
Zone
Alm/Rest.
Zone
Troub/Tam
Alm/Rest.
Zone
Fa u l t / Re st .
Zone Alm/Rest. Zone
Troub/Tam
Alm/Rest.
Zone
Fa u l t / Re st .
St andard Delay, Auxiliary Delay,
Instant, Interior, Int erior Delay,
Int erior St ay/Away, Delay
St a y / A w a y
(1 ) 3 A (3) 8 3 (3) 8A BA- ZZZ/ BH-ZZZ TA - ZZZ/TR-ZZZ UT- ZZZ/ UJ-ZZZ
Standard Fire, Delayed Fire, Auto
Ver if y Fi re
(1 ) 1A (3) 73 (3 ) 73 FA - ZZZ/FR-ZZZ FT- ZZZ/FJ- ZZZ FT- ZZZ/ FJ-ZZZ
Wat erf lo w (1 ) 1 3 (3) 73 (3) 73 SA - ZZZ/ SH-ZZZ ST- ZZZ/SJ- ZZZ ST-ZZZ/SJ-ZZZ
Fire Sup ervisor y (2 ) A A (3 ) 73 (3 ) 7 3 FS-ZZZ/ FR-ZZZ FT-ZZZ/FJ-ZZZ FT- ZZZ/ FJ-ZZZ
LINKS Supervisory (3) 8A (3) 8A (3) 8A US-ZZZ/UR-ZZZ US-ZZZ/UR-ZZZ US-ZZZ/UR-ZZ-
Z
24Hr Bell, 24Hr Bell/Buzzer, 24Hr
Buzzer
(1 ) 3 A (3) 8 3 (3) 8A BA- ZZZ/ BH-ZZZ TA - ZZZ/TR-ZZZ UT- ZZZ/ UJ-ZZZ
24 Hr Tech n i cal (1 ) 5 A (3) 83 (3) 8A UA-ZZZ/UH- ZZZ TA-ZZZ/TR-ZZZ UT- ZZZ/ UJ-ZZZ
24 Hr Gas (1 ) 5A (3) 83 (3 ) 8A GA- ZZZ/ GH- ZZZ TA-ZZZ/TR-ZZZ UT- ZZZ/UJ-ZZZ
24 Hr Heat (1 ) 5A (3) 83 (3 ) 8A KA - ZZZ/KH-ZZZ TA -ZZZ/TR-ZZZ UT- ZZZ/ UJ-ZZZ
24 Hr M ed ical (1 ) AA (3) 8 3 (3) 8A M A- ZZZ/ M H-ZZZ TA -ZZZ/TR-ZZZ UT- ZZZ/ UJ-ZZZ
24 Hr Emerg ency (1) A 1 (3) 83 (3) 8A QA- ZZZ/ QH- ZZZ TA -ZZZ/TR-ZZZ UT- ZZZ/ UJ-ZZZ
24 Hr Wat er (1 ) 5A (3) 83 (3 ) 8A WA- ZZZ/ W H- ZZZ TA-ZZZ/ TR-ZZZ UT- ZZZ/UJ-ZZZ
24 Hr Freeze (1 ) 5A (3 ) 83 (3 ) 8 A ZA- ZZZ/ZH- ZZZ TA -ZZZ/TR-ZZZ UT- ZZZ/ UJ-ZZZ
24 Hr Ho l dup (1 ) 2 2 (3) 83 (3) 8A HA- ZZZ/HH- ZZZ TA-ZZZ/TR-ZZZ UT- ZZZ/UJ-ZZZ
24Hr Panic (1) 2A (3) 83 (3) 8A PA-ZZZ/PH-ZZZ TA-ZZZ/TR-ZZZ UT-ZZZ/UJ-ZZZ
Lat chi n g 2 4Hr (1 ) 3A (3) 83 (3 ) 8 A BA -ZZZ/BH-ZZZ TA- ZZZ/TR-ZZZ UT-ZZZ/ UJ-ZZZ
Momentary Arm, Maintained Arm n/a n/a n/a n/a n/a n/a
Forced Answ er n/a n/a n/a n/a n/a n/a
LINKS An sw er n/a n/a n/a n/a n/a n/a
AC Delay n/a n/a n/a n/a n/a n/a
* If Contact ID is used, the above reporting codes are suggested. * * ZZZ = zo n es 001-128
Suggested Contact ID Event Codes: The numbers in brackets are not programmable. The two-digit number following the brackets is the program
ble reporting code.
Medical Alarms
(1)AA Medical
(1)A1 Pendant Transmitter
(1)A2 Fail to Report In
Fire Alarms
(1)1A Fire Alarm
(1)11 Smoke
(1)12 Combustion
(1)13 Water Flow
(1)14 Heat
(1)15 Pull Station
(1)16 Duct
(1)17 Flame
(1)18 Near Alarm
Panic Alarms
(1)2A Panic
(1)21 Duress
(1)22 Silent
(1)23 Audible
Burglar Alarms
(1)3A Burglary
(1)31 Perimeter
(1)32 Interior
(1)33 24 Hour
(1)34 Entry / Exit
(1)35 Day / Night
(1)36 Outdoor
(1)37 Tamper
(1)38 Near Alarm
General Alarms
(1)4A General Alarm
(1)43 Exp. module failure
(1)44 Sensor tamper
(1)45 Module Tamper
24 Hour Non-Burglary
(1)5A 24 Hour non-Burg
(1)51 Gas detected
(1)52 Refrigeration
(1)53 Loss of Heat
(1)54 Water Leakage
(1)55 Foil Break
(1)56 Day Trouble
(1)57 Low bottled Gas level
(1)58 High Temp
(1)59 Low Temp
(1)61 Loss of Air Flow
