Communications Programming
39
SECTION 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
force armed during auto-arming. If disabled, no partial clos-
ing reporting code will be sent (default=Yes).
• PC ID Restores: If enabled, the zone restoral reporting codes
will be transmitted instead of the zone alarm reporting codes
to identify the manually bypassed and force armed zones
upon auto-arming. If disabled, the zone alarm reporting codes
will be sent (default=No).
• TLM Enabled: If enabled, the system will test for telephone
line faults. The keypads will indicate any faults detected
(default=Yes).
• TLM Aud Bell: If enabled, all bells will be audible when a
telephone line trouble is present and the partition is armed
(default=Yes).
• FTC Aud Bell: If enabled, a Failure To Communicate trouble
will cause the bell outputs to activate. If disabled, only the
keypads will annunciate the trouble (default=No).
• TLM + Alarm Aud: This option will determine whether the
burg bell outputs will activate when a Transmission Line
Monitoring trouble and an alarm occur simultaneously. If
enabled, the bells for the armed partition will sound.
• Ringback: If enabled, the partition keypad will beep 10 times
when a successful communication of a closing to the central
station occurs (default=No).
NOTE: If communications are being sent to more than one telephone
number, communications to all numbers will produce a ringback.
• Ringback Sqwk: If enabled, the partition keypad and the par-
tition bell outputs (Fire/Burg, Inv Fire/Burg, Burg and Invert
Burg) will squawk when a successful communication of a
closing to the central station occurs (default=No).
NOTE: The Ringback option must be enabled in order for this feature
to function.
• Periodic Test: If enabled, the panel will send a test transmis-
sion to the central station (default=No).
If this feature is enabled and a PC4701 module is enrolled on
the system, the panel will alternate sending the periodic test
transmission between Line 1 and Line 2 of the PC4701 so that
both communication paths are tested.
• Europe Dial: If enabled, the contact closure to the telephone
line is made in a 67/33 make/break ratio. This is the European
standard method of dialing (default=No).
NOTE: Do not enable this option for North American installations.
• Default Dial: With this option enabled, if panel’s first attempt
to call the central station fails, it will dial on every subsequent
attempt regardless of the presence of a dial tone. When dis
-
abled, if a ‘D’ for dial tone search precedes the telephone
number, the panel will not dial if dial tone is not present. See
12.1 ”Telephone Numbers’ for programming the telephone
numbers with dial tone search (default=Yes).
• Ph 1-2 Backup: If enabled, the panel will attempt to report to
the second telephone number if it is unable to communicate
using the first telephone number. The panel will attempt to
call for the number of times programmed as the Maximum
Number of Dialing Attempts. When used as a backup number,
the dialer direction options for the second telephone number
should be disabled (default=No).
• Ph 1-3 Backup: This option is similar to ’Ph 1-2 Backup’
except that the panel will backup to the third telephone number
instead of the second (default=No).
NOTE: If the ’Ph 1-2 Backup’ option is also enabled, the reporting
code will be sent to both the second and third telephone numbers if the
panel is unable to communicate using the first number.
• Ph 2-3 Backup: This option is similar to ’Ph 1-2 Backup’
except that the panel will attempt to report to the third tele
-
phone number if it is unable to communicate using the second
telephone number (default=No).
NOTE: If the ’Ph 1-2 Backup’ option is also enabled, the reporting
code will be sent to the second telephone number if the panel is
unable to communicate using the first number. If the panel also fails
when attempting to call the second telephone number, the panel will
send the reporting code to the third number.
• Busy Tone Det.: If enabled, when a busy tone is detected for
four seconds, the panel will hang-up and wait for the amount
of time programmed as the Busy Tone Delay before attempt
-
ing to redial. If disabled, the panel will not search for busy
tone when dialing the telephone number (default=No).
NOTE: This feature must not be used with the LINKS1000.
• 1300 Hz ID: If enabled, the panel emits a 1300Hz identifica-
tion tone from the time it dials to the time it hears the hand-
shake from the receiver. If disabled, no identification tone is
emitted (default=No).
NOTE: This option should not be used with Pager 2, Pager 3 or Con-
tact ID formats. This feature should not be used in North America.
• Alternate Dial: If enabled, the panel will alternate between
the first and second telephone numbers when attempting to
call the central station, regardless of the dialer direction set
-
tings. If disabled, the panel will follow the programmed
backup dialing procedure (default=No).
• SIA 1 Account #: See 12.6 ”Communicator Formats’ for
information.
• Auto Report SIA: See 12.6 ”Communicator Formats’ for
information.
• Test Tx in Min: If enabled, the test transmission timer will be
in minutes. If disabled, it will be in days. See
10.8 ”Test
Transmissions’ (default = No).
• Tx Delay in Min: If enabled, the transmission delay will be in
minutes. If disabled, it will be in seconds. See
10.9 ”Trans-
mission Delay’ (default = No).
• 2nd Line Flash: If enabled, the panel will use the standard
dialing routing with the following addition. If the panel
doesn’t detect a dial tone during the first five seconds, the
panel will flash the line (hang up and pick up again) for 90ms.
The panel will then search for a dial tone on the virtual line
(default = No).
NOTE: This option is for use in Sweden only. Do not enable in North
America. If this and the LINKS1000 are enabled, the LINKS dialing
procedure will be slightly different. The panel will backup to the
LINKS on the third attempt.
• 6 digit Acct: If enabled, the system and partition account
numbers will be six digits for the SIA format. If disabled, the
account numbers will be four digits (default=No).
• T-Link Enabled: This option must be set to [N] for a UL
Listed system. If enabled, a communications link between
this product and a receiver, DLS, computer or other devices
on a LAN/WAN will be used.
NOTE: A T-Link module must be connected to the PC-Link connector
on the panel.
Please refer to the T-Link Installation Manual for further informa-
tion.
12.5 Dialer Direction
Ref #: [000400XX02] where XX = telephone number 00-02
The Dialer Direction programming section determines which
reporting codes will be sent to which telephone number. Three
groups of reporting codes can be selected:
• alarms and restorals
• openings and closings
• all other miscellaneous codes
These groups can be programmed to communicate to any or all
telephone numbers.
By default, all reporting codes are sent to the first telephone num-
ber only. The dialer direction options are toggle options which are
either enabled ([Y]es) or disabled ([N]o). Dialer options are pro
-
grammed individually for each telephone number. The reporting
codes in each group are indicated in Appendix A ’Reporting
Codes’.
12.6 Communicator Formats
Ref #: [000400XX01] where XX = telephone number 00-02
Each telephone number must be assigned a format to communi-
cate with the central station. There are several different communi-
