40
cator formats available. The default format is 20 BPS 2300Hz
Handshake.
10 BPS 1400/2300Hz Handshake Formats
• Data = 1900 Hz
• Kissoff = 1400/2300 Hz
• Speed = 10 Baud
20 BPS 1400/2300Hz Handshake Formats
20 Bits Per Second is the standard fast format used on DCI,
Franklin, Sescoa and Vertex receivers.
• Data = 1800 Hz
• Kissoff = 1400/2300 Hz
• Speed = 20 Baud
These formats will send an account code to identify which cus-
tomer is sending the alarm, and a reporting code to identify the
type of alarm. Depending on the receiver, the account code must
be either three or four digits, and the reporting code must be either
one or two digits.
If the account code requires only three digits, program the system
ID code and each partition account code with 3 digits, followed
by a [0]. If you wish to send a zero in the account code, program it
with a HEX A. For example, to program account code 103 enter
’1A30’.
If the reporting code needs to be only one digit, program the sec-
ond digit as a [0]. For example, to program a reporting code as
’3,’ enter ’30’. To send a zero, program HEX A into the reporting
code. For example, to send reporting code ’30,’ program ’3A’.
For instructions on programming HEX digits, see 3.4 ”Program-
ming Hexadecimal Data’.
Contact ID
Contact ID is a specialized format that will communicate infor-
mation using tones rather than pulses. This format allows more
information to be sent faster than other formats. For example, in
addition to reporting a Zone 1 alarm, the Contact ID format can
also report the type of alarm, such as an Entry/Exit alarm.
To program Contact ID, a 2-digit number from Appendix A must
be entered for every event to be transmitted. The 2-digit number
determines the type of alarm. The panel will automatically gener
-
ate all other information, including the zone number.
Additional Notes on Contact ID
1. Account Numbers must be four digits.
2. All reporting codes must be two digits.
3. Substitute the HEX digit ’A’ for the zero (0).
4. To prevent the panel from reporting an event, the reporting
code should be programmed as [00] or [FF].
Please refer to Appendix A ’Reporting Codes’ and Appendix B
’Zone Reporting Codes’ for a list of suggested Contact ID Identi
-
fiers for each event.
Auto-Contact ID
Ref #: [000401] and scroll to option
When programmed, the Auto-Contact ID automatically generates
the Contact ID reporting codes for all events. Program [00] to dis
-
able the event from reporting.
NOTE: Several fire related reporting codes are set to 99 by default to
ensure they are transmitted. If using Contact ID, these code need to be
reprogrammed. See Appendix A for the specific codes.
Contact ID Identifier Toggle Options
• Partial Closing Identifier: This toggle option controls
whether the Partial Closing reporting code will be transmitted
with an identifier of 4 or 5 when using Contact ID.
• Opening After Alarm Identifier: This toggle option con-
trols whether the Opening After Alarm reporting code will be
transmitted with an identifier of 4 or 5 when using Contact
ID.
SIA FSK
SIA is a specialized format that will communicate information
quickly using Frequency Shift Keying (FSK) rather than pulses.
The SIA format will automatically generate the type of signal
being transmitted, such as Burglary, Fire, Panic etc. The 2-digit
reporting code is used to identify the zone or user code number.
NOTE: If you use a communication format other than Automatic SIA
for any of the backup telephone numbers, make sure that the appro
-
priate reporting codes are programmed.
AutoRep SIA
Ref #: [000401] and scroll to option
If the SIA format is selected, the panel can be programmed to auto-
matically generate all zone and user code numbers, thus eliminat-
ing the need to program these items.
If the ’AutoRep SIA’ toggle option is enabled, the panel will oper-
ate as follows:
1. If an event’s reporting code is programmed as [00], the panel
will not attempt to call the central station.
2. If the reporting code for an event is programmed as anything
from [01] to [FF], the panel will automatically generate the
zone or user code number.
The Communicator Call Direction options can be used to disable
the reporting of events such as openings and closings.
If the ’AutoRep SIA’ toggle option is disabled, the panel will oper-
ate as follows:
1. If an event’s reporting code is programmed as [00] or [FF], the
panel will not attempt to call central station.
2. If the reporting code for an event is programmed as anything
from [01] to [FE], the panel will send the programmed report
-
ing code.
For Communicator Toggle Option programming, please see 12.4
”Communicator Toggle Options’.
Zone Label Sent with Events
With this feature the installer can choose to have the zone label
transmitted along with the zone event, when using SIA. When this
option is enabled, whenever the panel transmits an event which
identifies the zone number it will transmit the programmed label
for that zone number immediately after the zone event. All four
-
teen characters of the label will be transmitted even if the pro-
grammed label is less than 14 characters.
NOTE: Installer must ensure that this feature is supported by the cen-
tral station receiver(s). When using this option the zone labels can
only use the following ASCII characters:
SIA 1 Account#
Ref #: [000401] and scroll to option
If the ’SIA 1 Account#’ toggle option is enabled, the SIA commu-
nication format will send the system ID code along with the parti-
tion number with each data transmission. If disabled, the
communication format will use all eight Partition ID codes to
identify partition events. If this option is enabled, partition
account numbers are not required.
Please refer to Appendix A ’Reporting Codes’ and Appendix B
’Zone Reporting Codes for a list of SIA identifiers.
SIA Transmission 4-Digit Option
This option controls whether the panel will transmit three or four
digits for the reporting code when using SIA. Four digits are
A - Z ASCII 65 to 90
a - z ASCII 97 to 122
0 - 9 ASCII 48 to 57
, ASCII 44
- ASCII 45
. ASCII 46
: ASCII 58
<space> ASCII 32
