Appendix B: Reporting Codes
Notes on Contact ID
The following is a list of Contact ID reporting codes. The first
digit (in parentheses) will automatically be sent by the control.
The last two digits are programmed to indicate specific informa
-
tion about the signal.
For example, if zone 1 is an entry/exit point, the alarm reporting
code could be programmed as [34]. The central station would
receive the following:
*BURG - ENTRY/EXIT - 1
In the above example, the ’1’ indicates the zone in alarm.
Notes on SIA Format
If the SIA 1 Account # option is selected, the panel will send the
system account code along with its data transmission (ref #
[000401], scroll to option). At the receiver, the transmission
would look similar to this example:
N Ri01 / BA 001
N = New Event
Ri01 = Partition /Area Identifier
BA = Burglary Alarm
001 = Zone 1
4-Digit Reporting Codes
When using 4-digit reporting codes a leading zero will be added
to all reporting codes except for the user numbers (0000 to 1500).
* A/R = alarms/restorals; O/C = openings/closings; O = other
** PPP = partition number; UUU = user number (user 1000 to 1500 = 999); ZZZ = zone number
Ref. # Reporting Code Code Sent When...
Dialer
Direction*
Contact
ID
SIA Auto Rep
Codes**
[00040300] Zone Alarms zone goes into alarm A/R
see Appendix B ’Zone Report-
ing Codes’
[00040301] Zone Restorals alarm condition has been restored A/R
[00040302] Zone Trouble/Tamper zone exhibits a trouble/tamper condition A/R
[00040303] Zone Trouble/Tamper Rest. trouble/tamper condition has cleared A/R
[00040304] Zone Fault zone exhibits a zone fault A/R
[00040305] Zone Fault Rest. zone fault condition has cleared A/R
[00040306] [F] Key Alarm/Rest. Keypad fire alarm (alarm and restore rep. codes sent
together)
A/R (1) 15 FA-000/FH-000
[00040306] [A] Key Alarm/Rest. Keypad auxiliary alarm (alarm and restore rep. codes
sent together)
A/R (1) AA MA-000/MH-000
[00040306] [P] Key Alarm/Rest. Keypad panic alarm (alarm and restore rep. codes
sent together)
A/R (1) 2A PA-000/PH-000
[00040307] Duress Alarm Duress code entered A/R (1) 21 HA-000
[00040307] Opening After Alarm partition disarmed with alarm in memory A/R (4/5) 58 OR-000
[00040307] Recent Closing alarm occurs within two minutes of partition arming A/R (4) 59 CR-000
[00040307] Cross Zone (Police Code) Alarm two zones on the same partition go into alarm within
the Police Code Time during any given armed period
(incl. 24Hr zones)
A/R (1) 39 BV-000
[00040307] Door Forced Alarm/Rest. (access control) door forced open alarm event occurs
(PC4820 only)
A/R (1) NONE DF-ZZZ/DR-ZZZ
[00040307] Door Open Too Long Alarm/
Rest.
(access control) door open too long events occur
(PC4820 only)
A/R (1) NONE DN-ZZZ/DH-
ZZZ
[00040307] Alarm Cancel a user presses the Cancel function key after the parti-
tion has gone into alarm
A/R (4) A6 BC-UUU
[00040308] General System Tamper/Rest. enrolled module with tamper inputs has a tamper
alarm
O (1) 45 TA-000/TR-000
[00040309] Keypad Lockout max. number of incorrect access codes has been
entered at a keypad
O (4) 21 JA-000
[00040309] 2-wire Alarm/Rest. 2-wire smoke alarm (PC4701 only) A/R (1) 11 FA-999/FH-999
[00040309] Waterflow Alarm/Rest. waterflow zone alarm (PC4701 only) A/R (1) 13 SA-998/SH-998
[00040309] 2-wire Trouble/Rest. 2-wire smoke zone has a trouble (open) condition
(PC4701 only)
A/R (3) 73 FT-999/FJ-999
