16.5 System Fault Squawk
If the Sys.Flt.Squawk option is turned on, when the system
detects a zone tamper, zone fault or a module tamper, all the bur
-
glary bell outputs will squawk once every 5 seconds. The
’squawks’ will be silenced when the alarm is silenced or a key is
pressed on that partition. By default this option is off.
Aux Supply Troub The AUX, SAUX+ or PGM terminals on the alarm control
panel are overloaded
TLM Trouble There is a trouble with the telephone line.
TLM TBL Line #1 There is a trouble on telephone line 1 (only generated when
using the PC4701 Fire Module).
TLM TBL Line #2 There is a trouble on telephone line 2 (only generated when
using the PC4701 Fire Module).
FTC Trouble The alarm control panel can no longer communicate with the
central monitoring station. The trouble is generated after the
programmed failed communication attempts. If a later attempt
to communicate is successful, the trouble is cleared.
Bell CCT Trouble The bell circuit is open (PC4020 or PC4702).
Fire Trouble A fire loop is open (indicated by the trouble sound; cannot be
silenced). If the alarm control panel loses communication with
any expansion module, all Fire/Burglary outputs will activate
once every 10 seconds until a keypress is made, or module
communication is restored.
2 Wire Smoke The fire zone on a PC4701 Fire Module is open. The keypad
will display ’2-Wire Smoke’ until the trouble is restored.
Ground Fault The earth ground (EGND) connection is shorted to a positive
voltage source or shorted to a non-earth ground potential.
Waterflow The Waterflow zone on a PC4701 Fire Module is open. The
keypad will display ’Waterflow TBL’ until the zone trouble is
restored.
Loss of Time This trouble is cleared when the system’s time and date are
reset.
Module Com Fault The panel has lost communications with a module. Check to
see if the module is connected properly, then do a system reset.
Only qualified service personnel can perform this function.
Combus Low Pwr Modules are not getting enough voltage from the Combus.
Check for proper connection of Combus, or repower the Com
-
bus, if required. Only qualified service personnel can perform
this function.
4204 Battery TBL The battery connected to any PC4204/PC4204CX relay output
module is low (module number indicated in reporting code
transmission and event buffer).
4204 AC Trouble A PC4204/PC4204CX relay output module loses incoming
AC power (keypad will be silent).
Display Trouble Condition
4204 AUX Trouble The Auxiliary supply on any PC4204/PC4204CX relay mod-
ule is overloaded.
LINKS Trouble A LINKS unit has one or more of the following trouble condi-
tions: loss of AC power, low battery, loss of cellular communi-
cation or a tamper fault.
DLS Fault TBL The control panel has failed to complete communications with
the downloading computer.
Device Fault A wireless zone has failed to report a zone supervisory (press
[*] to view which zone).
Device Low Batt A wireless zone has a low battery (press [*] to view which
zone/device).
Display Trouble Condition
Device Tamper A wireless zone has a tamper condition (press [*] to view
which zone).
Automation Fault The ESCORT4580 loses communication with the Automation
Output control module. If there is an AC trouble present, the
panel will not transmit the Automation Fault reporting code to
the central station.
4820 Battery Trou-
ble
The battery connected to a PC4820 module is low.
4820 AC Trouble A PC4820 module has lost AC power.
4820 Lock Trouble A PC4820 module has a trouble with one of its locking
devices. A lock trouble occurs when the lock power output is
overloaded or the lock power fuse has failed.
4820 Aux Trouble The PC4820’s Auxiliary (AUX) supply is overloaded.
4820 Rdr Pw TBL A PC4820 module’s card reader power output is overloaded or
the reader power fuse has failed.
Smoke Low Sens A WLS906 Smoke Detector’s sensitivity is low.
4164 Signal Tbl Wireless zone transmissions are not being received by a
PC4164 wireless receiver.
RF Jam Detected Wireless device transmissions not being received by a PC4164
wireless receiver
4702 AC TBL The PC4702 module has lost AC power.
4702 Battery TBL The battery connected to the PC4702 is low.
Bells Silenced Fire alarm signals have been silenced. Trouble will clear when
the system is reset (enter access code).
Insp. Test Active The fire inspector's test has been initiated. Trouble will clear
when the test mode is disabled.
Printer Off-Line The printer connected to the PC440X module is off-line.
DVAC Trouble The DVACS line from central station is not present, the mod-
ule has failed internal diagnostics or DVACS communications
have been shut down.
DataLink The DataLink application connected to the PC4401 module is
off-line.
4850 Battery TBL The battery connected to a PC4850 module is low.
4850 AC Trouble A PC4850 module has lost AC power.
4850 AUX Trouble The PC4850’s Auxiliary (AUX) supply is overloaded.
Alt. Comms AC
Trouble
The alternate communicator has lost AC power.
Alt. Comms Battery
TBL
The battery connected to an alternate communicator module is
low.
Alt. Comms FTC
Trouble
The alarm control panel can no longer communicate with the
central monitoring station. The trouble is generated after the
programmed failed communication attempts. If a later attempt
to communicate is successful, the trouble is cleared.
Alt. Comms Remote
Shutdown
The alternate communicator has been disabled by the
central station.
Alt. Comms Encrypt
Disabled
Alt. Comms Gen-
eral TX TBL
One of the following conditions has occurred:
• Radio not responding
• Not connected to central station
•No service
• Unstable signal
Alt. Comms TBL
XX
An unidentified trouble has occurred, XX is the trouble num-
ber. Please see the appropriate alternate communicator manual
for details.
Alt. Comms Low
Signal XX
The received signal strength is low, XX is the signal strength.
Display Trouble Condition
