Section 17: Local, Central & Remote
Station Fire Installation Instructions
17.1 Introduction
The PC4020CF is a UL/ULC Listed panel for [1] Central and
Remote Station Fire Monitoring [2] Local and Central Station
Burglary Alarm Monitoring and [3] Access Control (in conjunc
-
tion with PC4820). When used as a fire panel, all fire functions
must be configured to take priority over Burglary, Access Control
and other auxiliary functions.
The PC4020CF has a number of system functions established as
default values. These functions must be maintained to ensure the
Life-Safety integrity of the installation meets all applicable codes
and standards.
To ensure an appropriate installation, all applicable NFPA, UL
and local codes and standards should be reviewed. Local AHJ
(Authority Having Jurisdiction) should also be consulted prior to
installation to determine specific local requirements for a fire
alarm installation.
Information in this manual is intended to describe the fire func-
tionality of the equipment. Further information on the overall sys-
tem is contained in the companion manuals for this product and
must be consulted for a full understanding of operation, installa
-
tion and programming.
This manual lists a number of alarm initiating and alarm notifica-
tion devices for use with this equipment. Use of devices other
than those listed herein must be carefully evaluated for compati
-
bility. 2-wire smoke detectors other than those listed in this man-
ual cannot be used without voiding the listing status of the
equipment.
Remote downloading of a fire panel, once it has been put into
operation and is protecting a premises, is severely limited. See the
Upload/Download section of this manual for information on this
topic.
17.2 Hardware Description and Specifications
PC4020CF - Main Panel
• One - PC4050CR – red cabinet 14.8” x 12.0” x 4.9” with
space for two 12V, 7Ah sealed lead-acid rechargeable battery
• One - PC4020 Main Control Module which includes:
• 16 zones programmable for Fire or Burglary
• Two Programmable Outputs (each programmable as an
addressable device loop):
• 12 VDC, 50 mA max. each (standard output) or
• 12 VDC, 170 mA max. each (addressable loops)
• One switched AUX Power Supply – 12 VDC, 120 mA max.
• One unswitched AUX Power Supply – 12 VDC, 120 mA
max.
NOTE: Refer to the PC4020 Installation Manual for compatible
devices.
• One Supervised Bell circuit – 12 VDC, 700 mA max.
• Supervised Battery Charger – 12 VDC, 350 mA charging
current (continuous); 400mA max.
• Supervised Telephone Communicator (connects to PC4701
module)
• One - Power Transformer – 16.5 VAC, 40 VA
• One - Hardware package which includes:
• 16 EOL resistors (5,600)
• One Black cabinet plug
• One green grounding strap
• Mounting hardware for the PC4020A PCB
NOTE: The ESCORT4580 cannot be used with PC4020CF panels.
PC4701 - Fire Module
• One – Two-Wire Smoke detection zone
• Class ‘B’/Style ‘B’
• Accommodates up to 30 – 12 VDC 2-wire smoke detectors.
• One – Waterflow zone – Class ‘B’/Style ‘B’
• Two – Supervised Communicator outputs
• One – Fire Alarm actuated relay:
Form ‘C’, rated 2A, 30 VDC
• One – Fire Trouble actuated relay:
Form ‘C’, rated 2A, 30 VDC
• Terminal connections for house telephone
• Hardware to mount the module to the sidewall of the
PC4050CR enclosure
T-Link Local Area Network Communicator
The T-Link Local Area Network Communicator provides an effi-
cient method of communicating via a Local Area Network (LAN).
See the T-Link Installation Manual (part no. 29001007) for more
details.
PC4702BP - Bell Panel
• One - PC4052CR Red cabinet – 12” x 12” x 5” with space for
two 12 V
DC, 4.0Ah sealed lead-acid rechargeable batteries
• One PC4702 Dual Bell Zone module which includes:
• Two supervised Class ‘B’/Style ‘Y’ Bell outputs – 24 VDC
FWR, 1.8A each. Outputs supervised for opens, shorts and
ground with self-restoring short protection
• Supervised battery charger, 24 VDC, 350 mA charging cur-
rent for sealed lead-acid rechargeable batteries
• Power transformer – 28 VAC, 175 VA (mounted in cabinet)
• Combus connection terminals
• Hardware for mounting PC4702 module.
LCD4520 - Fire Keypad
Standard LCD keypad with red bezel for use with the PC4020CF
LCD4521 - Fire Keypad with Function Keys
LCD keypad with red lens and five function keys:
• Silence Trouble
• Silence Bells
•Fire Reset
• Fire Drill
•Lamp Test
NOTE: At least one LCD4520 or LCD4521 keypad must be used
with the PC4020CF.
NOTE: Maximum keypad current draw 55mA
PC4204/PC4204CXCF – Power Supply/Relay Module For
Fire
• One - PC4052CR red cabinet – 12” x 12” x 5” with space for
two 12 volt, 7.0 Ah sealed lead-acid rechargeable battery
• One - PC4204/PC4204CX Power Supply/Relay Module
which includes:
• Four programmable relays rated 2 A, 30 VDC
• Unswitched Aux. Power Supply – 12 VDC, 550mA max.
• NC tamper input
• Supervised battery charger – 12 VDC, 350mA charging cur-
rent for sealed lead-acid rechargeable batteries
