71
* A/R = alarms/restorals; O/C = openings/closings; O = other
** PPP = partition number; UUU = user number (user 1000 to 1500 = 999); ZZZ = zone number
*** Not UL Listed. Do not use in conjunction with UL Listed systems
Ref. # Reporting Code Code Sent When...
Dialer
Direction*
Contact
ID
SIA Auto Rep
Codes**
[00040316] Closing Delinquency programmed number of days for delinquency has
expired without partition being armed
O (4) 54 CD-000
[00040316] Walk Test Enabled walk test mode entered O (6) A7 TS-000
[00040316] Walk Te st Disabled walk test complete O (6) A7 TE-000
[00040316] General System Trouble/Rest. indicates one or more of following:
PC4204/PC4204CX/PC4820/PC4702/PC4850***/
Alternate Communicator*** AC, battery and Aux
Supply troubles/rest., PC440X troubles, automation
fault, PC4164 RF jam
NOTE: When the system is being used in a fire appli-
cations, a General System trouble should be consid-
ered as a Fire trouble.
O (3) 3A YX-000/YZ-000
[00040316] General Device Low Battery/
Rest.
Wireless zones/pendants (WLS908) 009-128;
handheld keypads (WLS910)
wireless keys (WLS909)
O (3) 84 XT/XR-ZZZ
XT/XR-901-904
XT/XR-921-936
[00040316] Gen Module Comm Fault/Rest. control panel loses communications with connected
module(s)
O (3) 33 ET-000/ER-000
