Mazda 6 - Front Corner Sensor, Rear Corner Sensor

4 – 252
When Driving
Parking Sensor System
Front Corner Sensor, Rear Corner Sensor
Distance Detection area
Distance between vehicle and obstruction
Beeper sound
*1
Front/Rear Corner Sensor
Far distance
Approx. 50—38 cm (19.0—14.9 in)
Medium intermittent sound
Middle distance
Approx. 38—25 cm (14.9—9.8 in)
Fast intermittent sound
Close distance
Within approx. 25 cm (9.8 in)
Continuous sound
*1 The rate at which the intermittent sound beeps increases as the vehicle approaches the obstruction.
NOTE
If an obstruction is detected in a zone for 6 seconds or more, the beep sound is stopped
(except for the close-distance zone). If the same obstruction is detected in another zone,
the corresponding beep sound is heard.
