Mazda 6 - Brake Lights;Tail Lights, High-Mount Brake Light Replacement; Rear Direction Indicator Lights Replacement

6 – 56
Maintenance and Care
Owner Maintenance
5. Disconnect the connector from the unit
by pressing the tab on the connector
with your ¿ nger and pulling the
connector downward.
6. Turn the socket and bulb assembly
to remove it. Carefully remove the
bulb from its socket in the reÀ ector by
gently pulling it straight back out of the
socket.
7. Install the new bulb in the reverse order
of the removal procedure.
Brake lights/Tail lights, High-mount
brake light, Side-direction indicator
lights, Brake lights (With LED
headlights), Tail lights (With LED
headlights)
The LED bulb cannot be replaced as a
single unit because it is an integrated unit.
The LED bulb has to be replaced with
the unit. We recommend an Authorised
Mazda Repairer when the replacement is
necessary.
Rear direction indicator lights
S a l o o n
1. Make sure the ignition is switched off,
and the direction indicator switch is off.
2. Lift the boot mat.
3. (Left side)
Pull the centre of each plastic retainer
and remove the retainers and the
pocket.
(Right side)
Remove the pocket.
(Left side)
Removal
Installation
