Mazda 6 - To Secure the Jack

7 – 7
If Trouble Arises
Flat Tyre
2 . (With spare tyre)
Remove the cargo sub-compartment.
(Without spare tyre)
Rotate the shopping bag hook out of
its retainer and set the luggage board
against it.
(With spare tyre)
(Without spare tyre)
Cargo sub-compartment
3. Remove the pocket by pulling the tab.
4. Turn the wing bolt and jack screw
anticlockwise.
Wing bolt
Jack screw
To secure the jack
1. Insert the wing bolt into the jack with
the jack screw pointing to the front
and turn the wing bolt clockwise to
temporarily tighten it.
2. Turn the jack screw in the direction
shown in the ¿ gure.
Wing bolt
Jack screw
3. Turn the wing bolt completely to secure
the jack.
