Mazda 6 - Boot Light (Saloon) Replacement; Luggage Compartment Light (Wagon) (LED Type) Replacement

6 – 62
Maintenance and Care
Owner Maintenance
Courtesy lights
3. Install the new bulb in the reverse order
of the removal procedure.
Boot light (Saloon)
1. Press both sides of the lens cap to
remove it.
2. Disconnect the bulb by pulling it out.
3. Install the new bulb in the reverse order
of the removal procedure.
Luggage compartment light (Wagon)
(LED type)
The LED bulb cannot be replaced as a
single unit because it is an integrated unit.
The LED bulb has to be replaced with
the unit. We recommend an Authorised
Mazda Repairer when the replacement is
necessary.
(Bulb type)
1. Wrap a small À athead screwdriver
with a soft cloth to prevent damage to
the lens and remove the lens unit by
carefully prying on the edge of the lens
unit with the À athead screwdriver.
2. Disconnect the electrical connector
from the bulb by pressing the tab on the
connector with your ¿ nger and pulling
the connector.
