Mazda 6 - High-Beam Bulbs;Running Lights (with Running Lights) Replacement

6 – 50
Maintenance and Care
Owner Maintenance
High-beam bulbs/Running lights (With
running lights)
(Left side)
1. Make sure the ignition is switched off,
and the headlight switch is off.
2. Lift the bonnet.
3. Remove the clip.
4. Move the air cleaner cover and create a
space large enough to work in.
5. Turn the cover anticlockwise and
remove it.
6. Turn the socket and bulb assembly
anticlockwise and remove it.
7. Install the new bulb in the reverse order
of the removal procedure.
(Right side)
1. Make sure the ignition is switched off,
and the headlight switch is off.
2. Lift the bonnet.
