Mazda 6 - Page 617

6 – 49
Maintenance and Care
Owner Maintenance
3. Pull the centre of each plastic retainer
and remove the retainers.
Removal
Installation
4. Turn the screw anticlockwise and
remove it, and then partially peel back
the mudguard.
5. Disconnect the connector from the unit
by pressing the tab on the connector
with your ¿ nger and pulling the
connector downward.
6. Turn the socket and bulb assembly
to remove it. Carefully remove the
bulb from its socket in the reÀ ector by
gently pulling it straight backward out
of the socket.
7. Install the new bulb in the reverse order
of the removal procedure.
