6 – 67
Maintenance and Care
Owner Maintenance
*Some models.
DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
18 WIPER 20 A Front window wiper and washer
19 HEATER 40 A Air conditioner
20 DCDC REG 30 A For protection of various circuits
*
21 ENGINE.IG1 7.5 A Engine control system
22 C/U IG1 15 A For protection of various circuits
23
H/L LOW L
HID L
15 A Headlight low beam (LH)
24 H/L LOW R 15 A Headlight low beam (RH)
25 ENGINE3 15 A Engine control system
26 ENGINE2 15 A Engine control system
27 ENGINE1 15 A Engine control system
28 AT 15 A Transaxle control system
*
, Ignition switch
29 H/CLEAN 20 A Headlight washer
*
30 A/C 7.5 A Air conditioner
31 AT PUMP 15 A Transaxle control system
*
32 STOP 10 A Brake lights, Rear fog light
*
33 R.WIPER 15 A Rear window wiper
*
, Theft-deterrent system
*
34 H/L HI 20 A Headlight high beam
35
HID R
ST.HEATER
15 A Heated steering wheel
*
36 FOG 15 A Front fog lights
*
37
7.5 A Engine control system
38 AUDIO2 7.5 A Audio system
39 GLOW SIG 5 A Engine control system
*
40 METER2 7.5 A Instrument cluster
*
41 METER1 10 A Instrument cluster
42 SRS1 7.5 A Air bag
43 BOSE 25 A Bose
®
Sound System-equipped model
*
44 AUDIO1 15 A Audio system
45 ABS/DSC S 30 A ABS, Dynamic stability control system
46 FUEL PUMP 15 A Fuel system
*
47 FUEL WARM 25 A Fuel warmer
*
48 TAIL 15 A Tail lights, Number plate lights
*
49
FUEL PUMP2
SCR2
25 A Fuel system
*
50 HAZARD 25 A
Hazard warning À ashers, Direction indicator lights, Tail lights,
Position lights, Number plate lights
51 DRL 15 A Running lights
*
52 R.OUTLET2 15 A Accessory sockets
