MCCORMICK X60.40 - Use of Reverse Shuttle under Load; Use of Reverse Shuttle with Clutch Pedal

107
Operation
5
Use of reverse shuttle under load
Thetractor’sdrivingdirectionisautomaticallyreversed
bypushingtheorangeleverattheleftofthesteering
wheelforwardsorbackwards(1).
Thereverseshuttleisautomaticallycontrolledthrough
thefollowingphases:
· DECELERATION
· STOP
· CHANGEOFDIRECTION
· ACCELERATION
Thespeedatwhichthesephasestakeplacebysoftwa-
re.
Warning:Reversingcanbeobtainedatanyspe-
ed.However,toprotectmechanicalpartsfrom
damage,thisoperationshouldbemadeONLYat
speedsUNDER10Kph.Abuzzersoundstowarn
fromreversingatspeedsover10Kph.Tocorrectly
engegethereverseshuttle,reduceyourspeedto
under10Kph.
Use of reverse shuttle with clutch pedal
Theclutchpedalisusedtoobtainsmallandprecise
movementsforcertainworkrequirements.
· Completelydepresstheclutchpedal(1).
· Shifttheorangeshuttlecontrollever.
· WaitforthereverseindicatorLEDtocomeon.
· Useyourfootonthepedaltoengagetheclutchgra-
duallyandletthetractormoveforwardorbackward
asrequired.
