MCCORMICK X60.40 - 7-Pin Power Socket for Trailer; Rest of World Tractors

Electrical system
237
8
WARNING: Always use specific personal safety devices
for each operation.
7-pin power socket for trailer
A7-polepowersocketisinstalledontherearofthetrac-
tor(1).Thissocketisusedtoconnectthelightcircuits
ofthetrailer.
Connections and correspondences for 7-pole power
socketaccordingtoISO-SAEstandards.
1.Lhturnindicator;
2.Notused(Foglights-ifequipped);
3.Earth;
4.Rhturnindicator;
5.Rhrearmarkerlight;
6.Brakelights;
7.Lhrearmarkerlight.
North American Tractors
Connections
Rest Of World Tractors
Connections
Pinnumber4and7arecontrolledthroughthekeyswitch.
Thesecircuitsareprotectedbya30Afuse.SeetheFuse
chapterinthismanual.
TERMINALN.CIRCUIT(CABLECOLOUR)
1.....................................................................GROUND(WHITE)
2............................................................. FIELDLIGHTS(BLACK)
3...........................................LEFTTURNINDICATOR(YELLOW)
4.........................................................AUXILIARYPOWER(RED)
5........................................... RIGHTTURNINDICATOR(GREEN)
6..............................................................TAILLAMPS(BROWN)
7.......................................................AUXILIARYPOWER(BLUE)
