MCCORMICK X60.40 - Ich Calibration Sub-Menu, Hitch Position Display; Ich Calibration Sequence; Ich Calibration Errors

72
Instruments and Programming
1.1.5.1 ICh Calibration sub-menu, hitch position display
Thiscalibrationdefinesthehitchpositiondisplay.
WhentheLCDshows"ICh"andthePTOdisplayshows"0",theoperatorhastopressthe"MENU"buttontoaccessthe
hitchcalibrationmenu.
NowtheLCDwillshow"1",i.e."readytostart".Theinstrumentiswaitingfortheoperatortolowerthehitchdowntomini-
mumheight.Whenthehitchreachestheminimumheight,press"MENU"tosavethelowestlimitofhitchtravel,which
isstoredas"0%".Thecode"10"isdisplayedfor2seconds,followedbythecode"11".Nowtheinstrumentiswaitingfor
theoperatortoraisethehitchtoitsupperlimit.MakesuretheUpperLimitControlissettomaximumposition.When
thehitchreachesthemaximumheight,press"MENU"tosavetheupperlimitofhitchtravel,whichisstoredas"100%".
Thecode"20"isdisplayedfor2seconds,followedbythecode"50"toshowthatthecalibrationwasproperlyperformed.
PressMENUforlongerthan2secondstoexitCalibrationandgotoanothermenu.
ICh calibration sequence
ICh calibration errors
  Calibrationindex
Display
PTO Description
100 CalibrationnotOK.Repeatthecalibrationprocedure
  Calibrationindex
Display
PTO Description
0 Calibrationmodenotaccessed
1 Readytostart-waitingforhitchdown
10 Hitchlowestlimitstored-0%
11 Waitingforhitchup
20 Hitchupperlimitstored-100%
50 CalibrationOK
