138

Operation

Lower Links

Thelowerlinkshavethreepositions.Whenchanging

thepositionofthelowerlinks,supportthelinkswhen

removingtheretainingpins.

Bothliftlinksmustbesetinthesameposition.

Rigid Position

Foroperationwithnoverticalmovement,installthe

retainingpinsintherearhole.

Float position

Foroperationwithverticalfloat,independentlyofeach

other,installtheretainingpinsinthefronthole.

Transport position

Top Link

Whennotbeingusedstorethetoplinkasshown

above.

Whenoperatingonthepublichighwaywithoutequip-

mentattachedalwaysstorethetoplinkcorrectly.
