Operating the power lift
- Selectthepowerliftoperatingmodebymeansofthe
modeselector(3).
 Position 1 - Turntheknobanti-clockwisefor
draftcontrolmode.Useforplou-
ghingandsimilaroperationsthat
requireconstanttractiveforce.
 Position 6 -  Turntheknobclockwise
  forpositioncontrolmode.The
  implementwillremainatacon
  stantheightordepth.
 Intermed. positions “Intermix”mode.
 (2 - 3 - 4 - 5) Combining position control
 and draft control; for use on
variablesoilsorwithsubsoilers,
etc.
-Usetheselector(6)tosetasuitabledescentspeed
forthetypeofimplementbeingused.
-Settheswitch(1)toworkingposition(A).
-Turnthecontrolknob(2)toobtainthecorrectworking
depth/height.
Working with tillage implements
- Iftheimplementpitches(makeslargeliftingand
loweringadjustments)indraftcontrolmode,turnthe
modeselectorknob(3)clockwisetointroducean
elementofpositioncontrol(Intermix).
 Thesensitivityoftheelectronicpowerlifttovaria-
tionsinthetractionforcerequiredinworkingcondi-
tionsisautomaticallycontrolledandthustheopera-
torneednotintervenetomakecorrections.
Intermix/draft/position control
adjustment
Tillagework:position3or4.
Ploughing:positions1-2-3-4.
Lightsoilturning:positions4-5.
Grubbing:position3or4.
Carriedimplement:position6(positioncontrol).
Thesesettingsarepurelyindicativeandmayvaryde-
pendingontheimplementusedandthesoil.
Headland manoeuvres
- Raisetheimplementattheendofthefieldbysetting
theswitch(1)toPos.C.Thearmslifttotheheight
setontheliftheightlimiter(7).Adjusttheliftheight
limitersothatifadriveshaftisconnectedbetween
thePTOandtheimplement,itisnottwistedinto
acuteangles.Thiswillalsoavoidwastingtimelifting
theimplementtotransportheight.
-Tore-engagetheimplement,simplyturntheswitch
(1)totheworkingposition(A).Theimplementwilllo-
weratthespeedsetwithselector(7)untilisreaches
thepositionselectedwithknob(2).
-Tomaketheimplementquicklyre-engagethesoil,press
thebutton(5).
