184

Maintenance

50 HOUR MAIN SERVICE

Clean cab air recirculation filter

Ifworkinginverydustyenvironment,thecabairrecircula-

tionfiltershouldbecleanedeitheratsuitableintervalsor

every50workhours.

OPERATION1

Removethefourscrewsfromtherecirculationgrille.

OPERATION2

Removetherecirculationgrilleandthefilter.

OPERATION3

Cleanthefilterusingmildsoapandwater.Rinsewithclear

waterandsqueezeouttheexcess.

OPERATION4

Installthefilterintherecirculationgrille.

OPERATION5

Installthegrilleandfilter.Installandtightenthescrews.

WARNING: Always use specific personal safety devices

for each operation.
