MCCORMICK X60.40 - Check Engine Air Induction System; Filter Restriction Indicator Lamp

212
Maintenance
1000 HOUR MAIN SERVICE
Check engine air induction system
Check all hoses for damage and that hose clamps are
tight,correcttorque=3.4Nm.
Filter restriction indicator lamp
When the air filter restriction indicator lamp (1) on the
instrument cluster illuminates, the primary (outer) filter
element needs cleaning. Service the element after the
day'sworkiscompleted.
NOTE: If the air filter restriction indicator lamp* illuminates
after the primary filter has been serviced, check the fol-
lowing possible causes:
A. Secondary (inner) element is dirty.
B. Grille screen is dirty.
NOTE: If the service lamp of the air filter illuminates and
the intake system is clean, you should ask your dealer to
check the operation of the transmitter to the restriction
indicator lamp.
WARNING: Before cleaning the filter with
compressed air, wear individual protections,
in particular goggles and a mask to protect
your airways.
IMPORTANT: Dispose of filters correctly in accordance
with local regulations. Be responsible for the environment.
Theprimary(outer)filterisahighcapacityfilterdesigned
toprovideoptimumprotectiontotheengine.
The primary filter can be cleaned as required between
filterchanges.
Thesecondary(inner)filtergivesextraprotectiontothe
engineifthereisdamagetotheprimaryfilter.
IMPORTANT: THE SECONDARY (INNER) FILTER MUST
NOT BE CLEANED. REPLACE THE FILTER IF DAMAGED
OR DIRTY, OR AT THE THIRD CLEANING OF THE PRIMARY
FILTER.
1.PRIMARY(OUTER)FILTERELEMENT
2.SECONDARY(INNER)FILTERELEMENT
IMPORTANT: Only use approved air filters, these filters
have been specifically designed to provide superior en-
gine protection.
2
1
WARNING: Always stop the engine and remove the
ignition key before removing the filter elements.
